BetaFlight飞控AOCODARC-F7MINI固件编译

news 来源：原创 2023/3/20 23:39:37

BetaFlight飞控AOCODARC-F7MINI固件编译

1. 编译目标（AOCODARC-F7MINI）
2. 编译步骤
- Step 1 软件配置环境准备
- Step 2 获取开源代码
- Step 3 构建命令介绍
- Step 4 构建命令准备
- Step 5 厂家目标板查询
- Step 6 目标固件编译
- Step 7 目标固件清理
3. 参考资料

BetaFlight是一款非常出色的飞控航模开源软件，而且是基于GPL V3协议，所以相应的代码修改，必须开源出来。与PX4的BSD协议不一样，通常商业角度更多倾向于BSD协议。

本次编译主要是针对AOCODARC-F7MINI飞控板，采用最新的代码分支进行编译，以便进行功能验证。

1. 编译目标（AOCODARC-F7MINI）

控制器：STM32H722RET6
陀螺仪：MPU6500
气压计：BMP280
黑匣子：16MB
PWM输出：8CH
通用串口：5CH
输入电源：3-6SLipo
输出电源：5V/2.5A, 9V/3A
重量：6g
外形尺寸：29mm x 29mm
安装孔位：20mm x 20mm

在这里插入图片描述

2. 编译步骤

Step 1 软件配置环境准备

这里基于Ubuntu准备相关的软件配置环境。

$ sudo apt-get update
$ sudo apt-get install git
$ sudo apt-get install gitk git-gui

$ uname -a
Linux daniel-ThinkPad-SL410 5.15.0-58-generic #64~20.04.1-Ubuntu SMP Fri Jan 6 16:42:31 UTC 2023 x86_64 x86_64 x86_64 GNU/Linux$ lsb_release -a
No LSB modules are available.
Distributor ID: Ubuntu
Description:    Ubuntu 20.04.5 LTS
Release:        20.04
Codename:       focal

Step 2 获取开源代码

$ git clone git@github.com:betaflight/betaflight.git
Cloning into 'betaflight'...
remote: Enumerating objects: 199408, done.
remote: Counting objects: 100% (59/59), done.
remote: Compressing objects: 100% (47/47), done.
remote: Total 199408 (delta 13), reused 52 (delta 12), pack-reused 199349
Receiving objects: 100% (199408/199408), 379.34 MiB | 530.00 KiB/s, done.
Resolving deltas: 100% (138812/138812), done.
Updating files: 100% (3662/3662), done.$ cd betaflight$ git branch -a //当前是master主干分支
* masterremotes/origin/3.4.x-maintenanceremotes/origin/3.5.x-akk_vtx_fixremotes/origin/3.5.x-maintenanceremotes/origin/4.0.x-maintenanceremotes/origin/4.1-maintenanceremotes/origin/4.2-maintenanceremotes/origin/4.3-maintenanceremotes/origin/HEAD -> origin/masterremotes/origin/akk_vtx_fixremotes/origin/at32-developmentremotes/origin/broken-usb-rescueremotes/origin/fix_pull_request_templateremotes/origin/fix_timer_channel_countremotes/origin/masterremotes/origin/v3.2.x-maintenanceremotes/origin/v3.3.x-akk_vtx_fixremotes/origin/v3.3.x-maintenanceremotes/origin/v3.4.x-akk_vtx_fix

Step 3 构建命令介绍

在betaflight目录下，直接敲make help，脚本会显示命令所支持的参数。

这个还是非常C的工程，应为他采用了Makefile。不过作为用户就不要去研究里面的东东了。而且也没必要耗费大量的时间去构建所有目标板的固件，我们只需要确认并编译自己硬件的固件即可。

$ make helpMakefile for the betaflight firmwareUsage:make [V=<verbosity>] [TARGET=<target>] [OPTIONS="<options>"]
Or:make <target> [V=<verbosity>] [OPTIONS="<options>"]Valid TARGET values are: SITL STM32F405 STM32F411 STM32F745 STM32F7X2 STM32G47X STM32H723 STM32H730 STM32H743 STM32H750V                 : Set verbosity level based on the V= parameterV=0 LowV=1 High
compile_file takes two arguments: (1) optimisation description string and (2) optimisation compiler flag
all               : Build all currently built targets
all_all : Build all targets (including legacy / unsupported)
clean             : clean up temporary / machine-generated files
test_clean        : clean up temporary / machine-generated files (tests)
<TARGET>_clean    : clean up one specific target (alias for above)
clean_all         : clean all valid targets
<TARGET>_flash    : build and flash a target
tty_flash         : flash firmware (.hex) onto flight controller via a serial port
dfu_flash         : flash firmware (.bin) onto flight controller via a DFU mode
st-flash          : flash firmware (.bin) onto flight controller
<TARGET>_zip    : build target and zip it (useful for posting to GitHub)
<TARGET>_rev    : build target and add revision to filename
unbrick           : unbrick flight controller
cppcheck          : run static analysis on C source code
version           : print firmware version
help              : print this help message and exit
targets           : print a list of all valid target platforms (for consumption by scripts)
target-mcu        : print the MCU type of the target
targets-by-mcu    : make all targets that have a MCU_TYPE mcu
targets-f4        : make all F4 targets
targets-f7        : make all F7 targets
test              : run the Betaflight test suite
junittest         : run the Betaflight test suite, producing Junit XML result files.
test-representative: run a representative subset of the Betaflight test suite (i.e. run all tests, but run each expanded test only for one target)
test-all: run the Betaflight test suite including all per-target expanded tests
test_help         : print the help message for the test suite (including a list of the available tests)
test_versions         : print the compiler versions used for the test suite
test_%            : run test 'test_%' from the test suite
arm_sdk_install   : Install Arm SDK
arm_sdk_clean     : Uninstall Arm SDK

Step 4 构建命令准备

编译之前首先需要安装编译工具。各地的网络情况不一样，所以下载会遇到失败，请耐性尝试。

$ make arm_sdk_install
mkdir -p tools
mkdir -p downloads
Warning: Illegal date format for -z, --time-cond (and not a file name).
Warning: Disabling time condition. See curl_getdate(3) for valid date syntax.% Total    % Received % Xferd  Average Speed   Time    Time     Time  CurrentDload  Upload   Total   Spent    Left  Speed
100   252  100   252    0     0    205      0  0:00:01  0:00:01 --:--:--   20540  149M   40 60.4M    0     0  60132      0  0:43:32  0:17:34  0:25:58     0raspistill -o a.jpg -t 1000
curl: (56) OpenSSL SSL_read: Connection timed out, errno 110
make: *** [make/tools.mk:67: downloads/gcc-arm-none-eabi-10.3-2021.10-x86_64-linux.tar.bz2] Error 56
$ rm downloads/gcc-arm-none-eabi-10.3-2021.10-x86_64-linux.tar.bz2
$ make arm_sdk_install
Warning: Illegal date format for -z, --time-cond (and not a file name).
Warning: Disabling time condition. See curl_getdate(3) for valid date syntax.% Total    % Received % Xferd  Average Speed   Time    Time     Time  CurrentDload  Upload   Total   Spent    Left  Speed
100   252  100   252    0     0     43      0  0:00:05  0:00:05 --:--:--    63
100  149M  100  149M    0     0   215k      0  0:11:51  0:11:51 --:--:--  298k

注：有的时候会出现本地编译器版本太低的情况，需要执行上面的arm_sdk_install进行工具升级安装。

$ make targets
make/tools.mk:270: *** **ERROR** your arm-none-eabi-gcc is '10.2.1', but '10.3.1' is expected. Override with 'GCC_REQUIRED_VERSION' in make/local.mk or run 'make arm_sdk_install' to install the right version automatically in the tools folder of this repo.  Stop.

Step 5 厂家目标板查询

当前手头硬件板子是否在BetaFlight的支持列表中，查询方式如下：

$ make targets
Valid targets:       SITL STM32F405 STM32F411 STM32F745 STM32F7X2 STM32G47X STM32H723 STM32H730 STM32H743 STM32H750
Built targets:       SITL STM32F405 STM32F411 STM32F745 STM32F7X2 STM32G47X STM32H723 STM32H730 STM32H743 STM32H750
Default target:      STM32F405

鉴于产品规格：“控制器：STM32H722RET6”，所以在编译时需要选择“STM32F7X2”

Step 6 目标固件编译

BetaFlight在飞控代码上是基于MCU选型来区分目标代码，而相应的硬件配置通过unified-targets进行配置。

注：这是一种系统角度的软件代码设计思想，是非常好的设计思路，值得学习和借鉴！

$ make STM32F7X2
Building STM32F7X2
make[1]: Entering directory '/home/daniel/Work/betaflight'
make -j ./obj/betaflight_4.4.0_STM32F7X2.hex
make[2]: Entering directory '/home/daniel/Work/betaflight'
rm -f ./obj/main/STM32F7X2/.efhash_*
EF HASH -> ./obj/main/STM32F7X2/.efhash_d41d8cd98f00b204e9800998ecf8427e
%% startup_stm32f722xx.s
%% (optimised) ./src/main/startup/system_stm32f7xx.c
%% (speed optimised) ./src/main/drivers/accgyro/accgyro_mpu.c
%% (optimised) ./src/main/drivers/adc_stm32f7xx.c
%% (optimised) ./src/main/drivers/audio_stm32f7xx.c
%% (speed optimised) ./src/main/drivers/bus_i2c_hal.c
%% (size optimised) ./src/main/drivers/bus_i2c_hal_init.c
%% (size optimised) ./src/main/drivers/bus_i2c_timing.c
%% (optimised) ./src/main/drivers/dma_stm32f7xx.c
%% (size optimised) ./src/main/drivers/light_ws2811strip_hal.c
%% (size optimised) ./src/main/drivers/transponder_ir_io_hal.c
%% (speed optimised) ./src/main/drivers/bus_spi_ll.c
%% (optimised) ./src/main/drivers/persistent.c
%% (optimised) ./src/main/drivers/dshot_bitbang.c
%% (optimised) ./src/main/drivers/dshot_bitbang_decode.c
%% (optimised) ./src/main/drivers/dshot_bitbang_ll.c
%% (speed optimised) ./src/main/drivers/pwm_output_dshot_hal.c
%% (speed optimised) ./src/main/drivers/pwm_output_dshot_shared.c
%% (optimised) ./src/main/drivers/timer_stm32f7xx.c
%% (optimised) ./src/main/drivers/timer_hal.c
%% (optimised) ./src/main/drivers/system_stm32f7xx.c
%% (optimised) ./src/main/drivers/serial_uart_hal.c
%% (optimised) ./src/main/drivers/serial_uart_stm32f7xx.c
%% (optimised) ./src/main/drivers/sdio_f7xx.c
%% (size optimised) ./src/main/drivers/accgyro/accgyro_spi_lsm6dso_init.c
%% (size optimised) ./src/main/drivers/accgyro/accgyro_spi_icm20689.c
%% (size optimised) ./src/main/drivers/accgyro/accgyro_mpu6050.c
%% (speed optimised) ./src/main/drivers/accgyro/accgyro_spi_lsm6dso.c
%% (speed optimised) ./src/main/drivers/accgyro/accgyro_mpu3050.c
%% (optimised) ./src/main/drivers/accgyro/accgyro_spi_l3gd20.c
%% (optimised) ./src/main/drivers/accgyro/accgyro_spi_icm20649.c
%% (size optimised) ./src/main/drivers/accgyro/accgyro_fake.c
%% (size optimised) ./src/main/drivers/accgyro/accgyro_spi_icm426xx.c
%% (speed optimised) ./src/main/drivers/accgyro/accgyro_spi_bmi270.c
%% (optimised) ./src/main/drivers/accgyro/gyro_sync.c
%% (size optimised) ./src/main/drivers/accgyro/accgyro_spi_mpu6500.c
%% (size optimised) ./src/main/drivers/accgyro/accgyro_spi_mpu9250.c
%% (speed optimised) ./src/main/drivers/accgyro/accgyro_spi_bmi160.c
%% (size optimised) ./src/main/drivers/accgyro/accgyro_spi_mpu6000.c
%% (size optimised) ./src/main/drivers/accgyro/accgyro_mpu6500.c
%% (optimised) lib/main/BoschSensortec/BMI270-Sensor-API/bmi270_maximum_fifo.c
%% (size optimised) ./src/main/drivers/barometer/barometer_bmp085.c
%% (size optimised) ./src/main/drivers/barometer/barometer_ms5611.c
%% (size optimised) ./src/main/drivers/barometer/barometer_qmp6988.c
%% (size optimised) ./src/main/drivers/barometer/barometer_2smpb_02b.c
%% (size optimised) ./src/main/drivers/barometer/barometer_lps.c
%% (optimised) ./src/main/drivers/barometer/barometer_dps310.c
%% (size optimised) ./src/main/drivers/barometer/barometer_fake.c
%% (optimised) ./src/main/drivers/barometer/barometer_bmp388.c
%% (size optimised) ./src/main/drivers/barometer/barometer_bmp280.c
%% (optimised) ./src/main/drivers/compass/compass_mpu925x_ak8963.c
%% (size optimised) ./src/main/drivers/compass/compass_lis3mdl.c
%% (size optimised) ./src/main/drivers/compass/compass_ak8963.c
%% (size optimised) ./src/main/drivers/compass/compass_ak8975.c
%% (size optimised) ./src/main/drivers/compass/compass_hmc5883l.c
%% (size optimised) ./src/main/drivers/compass/compass_fake.c
%% (size optimised) ./src/main/drivers/compass/compass_qmc5883l.c
%% (speed optimised) ./src/main/drivers/max7456.c
%% (size optimised) ./src/main/drivers/vtx_rtc6705.c
%% (size optimised) ./src/main/drivers/vtx_rtc6705_soft_spi.c
%% (optimised) ./src/main/rx/cc2500_common.c
%% (optimised) ./src/main/rx/cc2500_frsky_shared.c
%% (optimised) ./src/main/rx/cc2500_frsky_d.c
%% (optimised) ./src/main/rx/cc2500_frsky_x.c
%% (optimised) ./src/main/rx/cc2500_sfhss.c
%% (optimised) ./src/main/rx/cc2500_redpine.c
%% (optimised) ./src/main/rx/a7105_flysky.c
%% (optimised) ./src/main/rx/cyrf6936_spektrum.c
%% (optimised) ./src/main/drivers/rx/expresslrs_driver.c
%% (optimised) ./src/main/rx/expresslrs.c
%% (optimised) ./src/main/rx/expresslrs_common.c
%% (optimised) ./src/main/rx/expresslrs_telemetry.c
%% (optimised) ./src/main/drivers/rx/rx_cc2500.c
%% (optimised) ./src/main/drivers/rx/rx_a7105.c
%% (optimised) ./src/main/drivers/rx/rx_cyrf6936.c
%% (optimised) ./src/main/drivers/rx/rx_sx127x.c
%% (optimised) ./src/main/drivers/rx/rx_sx1280.c
%% arm_bitreversal2.S
%% (optimised) ./src/main/drivers/flash.c
%% (optimised) ./src/main/drivers/flash_m25p16.c
%% (optimised) ./src/main/drivers/flash_w25n01g.c
%% (optimised) ./src/main/drivers/flash_w25q128fv.c
%% (optimised) ./src/main/drivers/flash_w25m.c
%% (optimised) ./src/main/io/flashfs.c
%% (optimised) ./src/main/drivers/usb_msc_common.c
%% (optimised) ./src/main/drivers/usb_msc_f7xx.c
%% (optimised) ./src/main/msc/usbd_storage.c
%% (optimised) ./src/main/msc/usbd_storage_sdio.c
%% (optimised) ./src/main/msc/usbd_storage_sd_spi.c
%% (optimised) ./src/main/msc/usbd_storage_emfat.c
%% (optimised) ./src/main/msc/emfat.c
%% (optimised) ./src/main/msc/emfat_file.c
%% (optimised) ./src/main/build/build_config.c
%% (optimised) ./src/main/build/debug.c
%% (optimised) ./src/main/build/debug_pin.c
%% (optimised) ./src/main/build/version.c
%% (optimised) ./src/main/target/STM32F7X2/target.c
%% (size optimised) ./src/main/main.c
%% (optimised) ./src/main/pg/rx_spi_cc2500.c
%% (optimised) ./src/main/pg/motor.c
%% (optimised) ./src/main/pg/rcdevice.c
%% (optimised) ./src/main/pg/pg.c
%% (optimised) ./src/main/pg/pin_pull_up_down.c
%% (optimised) ./src/main/pg/bus_i2c.c
%% (optimised) ./src/main/pg/bus_spi.c
%% (optimised) ./src/main/pg/vcd.c
%% (optimised) ./src/main/pg/dyn_notch.c
%% (optimised) ./src/main/pg/pinio.c
%% (optimised) ./src/main/pg/beeper_dev.c
%% (optimised) ./src/main/pg/rpm_filter.c
%% (optimised) ./src/main/pg/vtx_io.c
%% (optimised) ./src/main/pg/board.c
%% (optimised) ./src/main/pg/rx.c
%% (optimised) ./src/main/pg/scheduler.c
%% (optimised) ./src/main/pg/adc.c
%% (optimised) ./src/main/pg/dashboard.c
%% (optimised) ./src/main/pg/displayport_profiles.c
%% (optimised) ./src/main/pg/rx_spi.c
%% (optimised) ./src/main/pg/timerup.c
%% (optimised) ./src/main/pg/gps.c
%% (optimised) ./src/main/pg/vtx_table.c
%% (optimised) ./src/main/pg/gps_rescue.c
%% (optimised) ./src/main/pg/flash.c
%% (optimised) ./src/main/pg/rx_pwm.c
%% (optimised) ./src/main/pg/mco.c
%% (optimised) ./src/main/pg/beeper.c
%% (optimised) ./src/main/pg/usb.c
%% (optimised) ./src/main/pg/bus_quadspi.c
%% (optimised) ./src/main/pg/timerio.c
%% (optimised) ./src/main/pg/max7456.c
%% (optimised) ./src/main/pg/stats.c
%% (optimised) ./src/main/pg/rx_spi_expresslrs.c
%% (optimised) ./src/main/pg/piniobox.c
%% (optimised) ./src/main/pg/sdcard.c
%% (optimised) ./src/main/pg/serial_uart.c
%% (optimised) ./src/main/pg/gyrodev.c
%% (optimised) ./src/main/pg/msp.c
%% (optimised) ./src/main/pg/sdio.c
%% (speed optimised) ./src/main/common/maths.c
%% (optimised) ./src/main/common/bitarray.c
%% (optimised) ./src/main/common/strtol.c
%% (optimised) ./src/main/common/crc.c
%% (optimised) ./src/main/common/huffman.c
%% (optimised) ./src/main/common/uvarint.c
%% (optimised) ./src/main/common/time.c
%% (speed optimised) ./src/main/common/sdft.c
%% (speed optimised) ./src/main/common/typeconversion.c
%% (optimised) ./src/main/common/string_light.c
%% (optimised) ./src/main/common/huffman_table.c
%% (speed optimised) ./src/main/common/encoding.c
%% (optimised) ./src/main/common/printf_serial.c
%% (speed optimised) ./src/main/common/filter.c
%% (optimised) ./src/main/common/sensor_alignment.c
%% (optimised) ./src/main/common/explog_approx.c
%% (optimised) ./src/main/common/gps_conversion.c
%% (optimised) ./src/main/common/streambuf.c
%% (optimised) ./src/main/common/printf.c
%% (optimised) ./src/main/common/colorconversion.c
%% (size optimised) ./src/main/config/config_eeprom.c
%% (size optimised) ./src/main/config/simplified_tuning.c
%% (optimised) ./src/main/config/config.c
%% (size optimised) ./src/main/config/config_streamer.c
%% (size optimised) ./src/main/config/feature.c
%% (size optimised) ./src/main/cli/cli.c
%% (size optimised) ./src/main/cli/settings.c
%% (speed optimised) ./src/main/drivers/adc.c
%% (optimised) ./src/main/drivers/dshot.c
%% (optimised) ./src/main/drivers/dshot_dpwm.c
%% (optimised) ./src/main/drivers/dshot_command.c
%% (speed optimised) ./src/main/drivers/buf_writer.c
%% (speed optimised) ./src/main/drivers/bus.c
%% (size optimised) ./src/main/drivers/bus_i2c_config.c
%% (optimised) ./src/main/drivers/bus_i2c_busdev.c
%% (optimised) ./src/main/drivers/bus_i2c_soft.c
%% (speed optimised) ./src/main/drivers/bus_quadspi.c
%% (speed optimised) ./src/main/drivers/bus_spi.c
%% (size optimised) ./src/main/drivers/bus_spi_config.c
%% (size optimised) ./src/main/drivers/bus_spi_pinconfig.c
%% (optimised) ./src/main/drivers/buttons.c
%% (optimised) ./src/main/drivers/display.c
%% (optimised) ./src/main/drivers/display_canvas.c
%% (optimised) ./src/main/drivers/dma_common.c
%% (optimised) ./src/main/drivers/dma_reqmap.c
%% (speed optimised) ./src/main/drivers/exti.c
%% (speed optimised) ./src/main/drivers/io.c
%% (optimised) ./src/main/drivers/light_led.c
%% (optimised) ./src/main/drivers/mco.c
%% (optimised) ./src/main/drivers/motor.c
%% (optimised) ./src/main/drivers/pinio.c
%% (optimised) ./src/main/drivers/pin_pull_up_down.c
%% (optimised) ./src/main/drivers/resource.c
%% (speed optimised) ./src/main/drivers/rcc.c
%% (speed optimised) ./src/main/drivers/serial.c
%% (size optimised) ./src/main/drivers/serial_pinconfig.c
%% (speed optimised) ./src/main/drivers/serial_uart.c
%% (size optimised) ./src/main/drivers/serial_uart_pinconfig.c
%% (optimised) ./src/main/drivers/sound_beeper.c
%% (optimised) ./src/main/drivers/stack_check.c
%% (speed optimised) ./src/main/drivers/system.c
%% (optimised) ./src/main/drivers/timer_common.c
%% (optimised) ./src/main/drivers/transponder_ir_arcitimer.c
%% (optimised) ./src/main/drivers/transponder_ir_ilap.c
%% (optimised) ./src/main/drivers/transponder_ir_erlt.c
%% (size optimised) ./src/main/fc/board_info.c
%% (optimised) ./src/main/fc/dispatch.c
%% (optimised) ./src/main/fc/hardfaults.c
%% (speed optimised) ./src/main/fc/tasks.c
%% (speed optimised) ./src/main/fc/runtime_config.c
%% (optimised) ./src/main/fc/stats.c
%% (optimised) ./src/main/io/beeper.c
%% (optimised) ./src/main/io/piniobox.c
%% (size optimised) ./src/main/io/serial.c
%% (optimised) ./src/main/io/smartaudio_protocol.c
%% (optimised) ./src/main/io/statusindicator.c
%% (optimised) ./src/main/io/tramp_protocol.c
%% (size optimised) ./src/main/io/transponder_ir.c
%% (size optimised) ./src/main/io/usb_cdc_hid.c
%% (optimised) ./src/main/io/usb_msc.c
%% (optimised) ./src/main/msp/msp.c
%% (optimised) ./src/main/msp/msp_box.c
%% (size optimised) ./src/main/msp/msp_serial.c
%% (speed optimised) ./src/main/scheduler/scheduler.c
%% (optimised) ./src/main/sensors/adcinternal.c
%% (optimised) ./src/main/sensors/battery.c
%% (optimised) ./src/main/sensors/current.c
%% (optimised) ./src/main/sensors/voltage.c
%% (optimised) ./src/main/target/config_helper.c
%% (size optimised) ./src/main/fc/init.c
%% (optimised) ./src/main/fc/controlrate_profile.c
%% (optimised) ./src/main/drivers/camera_control.c
%% (optimised) ./src/main/drivers/pwm_esc_detect.c
%% (speed optimised) ./src/main/drivers/pwm_output.c
%% (optimised) ./src/main/drivers/rx/rx_spi.c
%% (optimised) ./src/main/drivers/rx/rx_xn297.c
%% (optimised) ./src/main/drivers/rx/rx_pwm.c
%% (optimised) ./src/main/drivers/serial_softserial.c
%% (speed optimised) ./src/main/fc/core.c
%% (speed optimised) ./src/main/fc/rc.c
%% (optimised) ./src/main/fc/rc_adjustments.c
%% (speed optimised) ./src/main/fc/rc_controls.c
%% (optimised) ./src/main/fc/rc_modes.c
%% (optimised) ./src/main/flight/position.c
%% (optimised) ./src/main/flight/failsafe.c
%% (optimised) ./src/main/flight/gps_rescue.c
%% (speed optimised) ./src/main/flight/dyn_notch_filter.c
%% (speed optimised) ./src/main/flight/imu.c
%% (optimised) ./src/main/flight/feedforward.c
%% (speed optimised) ./src/main/flight/mixer.c
%% (size optimised) ./src/main/flight/mixer_init.c
%% (optimised) ./src/main/flight/mixer_tricopter.c
%% (speed optimised) ./src/main/flight/pid.c
%% (size optimised) ./src/main/flight/pid_init.c
%% (speed optimised) ./src/main/flight/rpm_filter.c
%% (optimised) ./src/main/flight/servos.c
%% (optimised) ./src/main/flight/servos_tricopter.c
%% (size optimised) ./src/main/io/serial_4way.c
%% (size optimised) ./src/main/io/serial_4way_avrootloader.c
%% (size optimised) ./src/main/io/serial_4way_stk500v2.c
%% (speed optimised) ./src/main/rx/ibus.c
%% (optimised) ./src/main/rx/jetiexbus.c
%% (optimised) ./src/main/rx/msp.c
%% (optimised) ./src/main/rx/pwm.c
%% (speed optimised) ./src/main/rx/frsky_crc.c
%% (speed optimised) ./src/main/rx/rx.c
%% (size optimised) ./src/main/rx/rx_bind.c
%% (speed optimised) ./src/main/rx/rx_spi.c
%% (optimised) ./src/main/rx/rx_spi_common.c
%% (speed optimised) ./src/main/rx/crsf.c
%% (optimised) ./src/main/rx/ghst.c
%% (speed optimised) ./src/main/rx/sbus.c
%% (speed optimised) ./src/main/rx/sbus_channels.c
%% (speed optimised) ./src/main/rx/spektrum.c
%% (speed optimised) ./src/main/rx/srxl2.c
%% (size optimised) ./src/main/io/spektrum_vtx_control.c
%% (optimised) ./src/main/io/spektrum_rssi.c
%% (speed optimised) ./src/main/rx/sumd.c
%% (optimised) ./src/main/rx/sumh.c
%% (speed optimised) ./src/main/rx/xbus.c
%% (speed optimised) ./src/main/rx/fport.c
%% (optimised) ./src/main/rx/msp_override.c
%% (speed optimised) ./src/main/sensors/acceleration.c
%% (size optimised) ./src/main/sensors/acceleration_init.c
%% (speed optimised) ./src/main/sensors/boardalignment.c
%% (optimised) ./src/main/sensors/compass.c
%% (speed optimised) ./src/main/sensors/gyro.c
%% (size optimised) ./src/main/sensors/gyro_init.c
%% (optimised) ./src/main/sensors/initialisation.c
%% (optimised) ./src/main/blackbox/blackbox.c
%% (optimised) ./src/main/blackbox/blackbox_encoding.c
%% (optimised) ./src/main/blackbox/blackbox_io.c
%% (size optimised) ./src/main/cms/cms.c
%% (size optimised) ./src/main/cms/cms_menu_blackbox.c
%% (size optimised) ./src/main/cms/cms_menu_failsafe.c
%% (size optimised) ./src/main/cms/cms_menu_firmware.c
%% (size optimised) ./src/main/cms/cms_menu_gps_rescue.c
%% (size optimised) ./src/main/cms/cms_menu_imu.c
%% (size optimised) ./src/main/cms/cms_menu_ledstrip.c
%% (size optimised) ./src/main/cms/cms_menu_main.c
%% (size optimised) ./src/main/cms/cms_menu_misc.c
%% (size optimised) ./src/main/cms/cms_menu_osd.c
%% (size optimised) ./src/main/cms/cms_menu_power.c
%% (size optimised) ./src/main/cms/cms_menu_saveexit.c
%% (size optimised) ./src/main/cms/cms_menu_vtx_common.c
%% (size optimised) ./src/main/cms/cms_menu_vtx_rtc6705.c
%% (size optimised) ./src/main/cms/cms_menu_vtx_smartaudio.c
%% (size optimised) ./src/main/cms/cms_menu_vtx_tramp.c
%% (size optimised) ./src/main/cms/cms_menu_persistent_stats.c
%% (size optimised) ./src/main/drivers/display_ug2864hsweg01.c
%% (size optimised) ./src/main/drivers/light_ws2811strip.c
%% (optimised) ./src/main/drivers/rangefinder/rangefinder_hcsr04.c
%% (optimised) ./src/main/drivers/rangefinder/rangefinder_lidartf.c
%% (size optimised) ./src/main/drivers/serial_escserial.c
%% (size optimised) ./src/main/drivers/vtx_common.c
%% (optimised) ./src/main/drivers/vtx_table.c
%% (size optimised) ./src/main/io/dashboard.c
%% (optimised) ./src/main/io/displayport_frsky_osd.c
%% (optimised) ./src/main/io/displayport_max7456.c
%% (optimised) ./src/main/io/displayport_msp.c
%% (optimised) ./src/main/io/displayport_oled.c
%% (optimised) ./src/main/io/displayport_srxl.c
%% (optimised) ./src/main/io/displayport_crsf.c
%% (optimised) ./src/main/io/displayport_hott.c
%% (optimised) ./src/main/io/frsky_osd.c
%% (optimised) ./src/main/io/rcdevice_cam.c
%% (optimised) ./src/main/io/rcdevice.c
%% (optimised) ./src/main/io/gps.c
%% (optimised) ./src/main/io/ledstrip.c
%% (optimised) ./src/main/io/pidaudio.c
%% (size optimised) ./src/main/osd/osd.c
%% (size optimised) ./src/main/osd/osd_elements.c
%% (size optimised) ./src/main/osd/osd_warnings.c
%% (optimised) ./src/main/sensors/barometer.c
%% (optimised) ./src/main/sensors/rangefinder.c
%% (optimised) ./src/main/telemetry/telemetry.c
%% (optimised) ./src/main/telemetry/crsf.c
%% (optimised) ./src/main/telemetry/ghst.c
%% (optimised) ./src/main/telemetry/srxl.c
%% (optimised) ./src/main/telemetry/frsky_hub.c
%% (optimised) ./src/main/telemetry/hott.c
%% (optimised) ./src/main/telemetry/jetiexbus.c
%% (optimised) ./src/main/telemetry/smartport.c
%% (optimised) ./src/main/telemetry/ltm.c
%% (optimised) ./src/main/telemetry/mavlink.c
%% (optimised) ./src/main/telemetry/msp_shared.c
%% (optimised) ./src/main/telemetry/ibus.c
%% (optimised) ./src/main/telemetry/ibus_shared.c
%% (optimised) ./src/main/sensors/esc_sensor.c
%% (size optimised) ./src/main/io/vtx.c
%% (size optimised) ./src/main/io/vtx_rtc6705.c
%% (size optimised) ./src/main/io/vtx_smartaudio.c
%% (size optimised) ./src/main/io/vtx_tramp.c
%% (size optimised) ./src/main/io/vtx_control.c
%% (size optimised) ./src/main/io/vtx_msp.c
%% (size optimised) ./src/main/cms/cms_menu_vtx_msp.c
%% (optimised) ./lib/main/STM32F7/Drivers/STM32F7xx_HAL_Driver/Src/stm32f7xx_hal_cortex.c
%% (optimised) ./lib/main/STM32F7/Drivers/STM32F7xx_HAL_Driver/Src/stm32f7xx_ll_rcc.c
%% (optimised) ./lib/main/STM32F7/Drivers/STM32F7xx_HAL_Driver/Src/stm32f7xx_hal_uart_ex.c
%% (optimised) ./lib/main/STM32F7/Drivers/STM32F7xx_HAL_Driver/Src/stm32f7xx_hal_dac_ex.c
%% (optimised) ./lib/main/STM32F7/Drivers/STM32F7xx_HAL_Driver/Src/stm32f7xx_hal.c
%% (optimised) ./lib/main/STM32F7/Drivers/STM32F7xx_HAL_Driver/Src/stm32f7xx_hal_adc.c
%% (optimised) ./lib/main/STM32F7/Drivers/STM32F7xx_HAL_Driver/Src/stm32f7xx_hal_pwr.c
%% (optimised) ./lib/main/STM32F7/Drivers/STM32F7xx_HAL_Driver/Src/stm32f7xx_hal_flash_ex.c
%% (optimised) ./lib/main/STM32F7/Drivers/STM32F7xx_HAL_Driver/Src/stm32f7xx_hal_flash.c
%% (optimised) ./lib/main/STM32F7/Drivers/STM32F7xx_HAL_Driver/Src/stm32f7xx_hal_spi_ex.c
%% (optimised) ./lib/main/STM32F7/Drivers/STM32F7xx_HAL_Driver/Src/stm32f7xx_hal_tim_ex.c
%% (optimised) ./lib/main/STM32F7/Drivers/STM32F7xx_HAL_Driver/Src/stm32f7xx_hal_pcd.c
%% (optimised) ./lib/main/STM32F7/Drivers/STM32F7xx_HAL_Driver/Src/stm32f7xx_hal_dma_ex.c
%% (optimised) ./lib/main/STM32F7/Drivers/STM32F7xx_HAL_Driver/Src/stm32f7xx_hal_rcc.c
%% (optimised) ./lib/main/STM32F7/Drivers/STM32F7xx_HAL_Driver/Src/stm32f7xx_ll_utils.c
%% (optimised) ./lib/main/STM32F7/Drivers/STM32F7xx_HAL_Driver/Src/stm32f7xx_ll_dma2d.c
%% (optimised) ./lib/main/STM32F7/Drivers/STM32F7xx_HAL_Driver/Src/stm32f7xx_hal_rtc_ex.c
%% (optimised) ./lib/main/STM32F7/Drivers/STM32F7xx_HAL_Driver/Src/stm32f7xx_ll_spi.c
%% (optimised) ./lib/main/STM32F7/Drivers/STM32F7xx_HAL_Driver/Src/stm32f7xx_ll_gpio.c
%% (optimised) ./lib/main/STM32F7/Drivers/STM32F7xx_HAL_Driver/Src/stm32f7xx_hal_i2c_ex.c
%% (optimised) ./lib/main/STM32F7/Drivers/STM32F7xx_HAL_Driver/Src/stm32f7xx_hal_usart.c
%% (optimised) ./lib/main/STM32F7/Drivers/STM32F7xx_HAL_Driver/Src/stm32f7xx_hal_pwr_ex.c
%% (optimised) ./lib/main/STM32F7/Drivers/STM32F7xx_HAL_Driver/Src/stm32f7xx_hal_rcc_ex.c
%% (optimised) ./lib/main/STM32F7/Drivers/STM32F7xx_HAL_Driver/Src/stm32f7xx_hal_uart.c
%% (optimised) ./lib/main/STM32F7/Drivers/STM32F7xx_HAL_Driver/Src/stm32f7xx_ll_dma.c
%% (optimised) ./lib/main/STM32F7/Drivers/STM32F7xx_HAL_Driver/Src/stm32f7xx_hal_dma.c
%% (optimised) ./lib/main/STM32F7/Drivers/STM32F7xx_HAL_Driver/Src/stm32f7xx_hal_exti.c
%% (optimised) ./lib/main/STM32F7/Drivers/STM32F7xx_HAL_Driver/Src/stm32f7xx_ll_usb.c
%% (optimised) ./lib/main/STM32F7/Drivers/STM32F7xx_HAL_Driver/Src/stm32f7xx_hal_tim.c
%% (optimised) ./lib/main/STM32F7/Drivers/STM32F7xx_HAL_Driver/Src/stm32f7xx_hal_pcd_ex.c
%% (optimised) ./lib/main/STM32F7/Drivers/STM32F7xx_HAL_Driver/Src/stm32f7xx_hal_spi.c
%% (optimised) ./lib/main/STM32F7/Drivers/STM32F7xx_HAL_Driver/Src/stm32f7xx_hal_gpio.c
%% (optimised) ./lib/main/STM32F7/Drivers/STM32F7xx_HAL_Driver/Src/stm32f7xx_hal_dac.c
%% (optimised) ./lib/main/STM32F7/Drivers/STM32F7xx_HAL_Driver/Src/stm32f7xx_hal_i2c.c
%% (optimised) ./lib/main/STM32F7/Drivers/STM32F7xx_HAL_Driver/Src/stm32f7xx_hal_rtc.c
%% (optimised) ./lib/main/STM32F7/Drivers/STM32F7xx_HAL_Driver/Src/stm32f7xx_ll_tim.c
%% (optimised) ./lib/main/STM32F7/Drivers/STM32F7xx_HAL_Driver/Src/stm32f7xx_hal_adc_ex.c
%% (optimised) ./lib/main/STM32F7/Middlewares/ST/STM32_USB_Device_Library/Core/Src/usbd_core.c
%% (optimised) ./lib/main/STM32F7/Middlewares/ST/STM32_USB_Device_Library/Core/Src/usbd_ctlreq.c
%% (optimised) ./lib/main/STM32F7/Middlewares/ST/STM32_USB_Device_Library/Core/Src/usbd_ioreq.c
%% (optimised) ./lib/main/STM32F7/Middlewares/ST/STM32_USB_Device_Library/Class/CDC/Src/usbd_cdc.c
%% (optimised) ./lib/main/STM32F7/Middlewares/ST/STM32_USB_Device_Library/Class/HID/Src/usbd_hid.c
%% (optimised) ./lib/main/STM32F7/Middlewares/ST/STM32_USB_Device_Library/Class/MSC/Src/usbd_msc.c
%% (optimised) ./lib/main/STM32F7/Middlewares/ST/STM32_USB_Device_Library/Class/MSC/Src/usbd_msc_bot.c
%% (optimised) ./lib/main/STM32F7/Middlewares/ST/STM32_USB_Device_Library/Class/MSC/Src/usbd_msc_data.c
%% (optimised) ./lib/main/STM32F7/Middlewares/ST/STM32_USB_Device_Library/Class/MSC/Src/usbd_msc_scsi.c
%% (optimised) ./src/main/drivers/sdcard.c
%% (optimised) ./src/main/drivers/sdcard_spi.c
%% (optimised) ./src/main/drivers/sdcard_standard.c
%% (optimised) ./src/main/io/asyncfatfs/asyncfatfs.c
%% (optimised) ./src/main/io/asyncfatfs/fat_standard.c
%% (optimised) ./src/main/drivers/sdcard_sdio_baremetal.c
%% (optimised) ./src/main/vcp_hal/usbd_desc.c
%% (optimised) ./src/main/vcp_hal/usbd_conf_stm32f7xx.c
%% (optimised) ./src/main/vcp_hal/usbd_cdc_hid.c
%% (optimised) ./src/main/vcp_hal/usbd_cdc_interface.c
%% (size optimised) ./src/main/drivers/serial_usb_vcp.c
%% (optimised) ./src/main/drivers/usb_io.c
%% (size optimised) lib/main/google/olc/olc.c
Linking STM32F7X2
Memory region         Used Size  Region Size  %age UsedITCM_RAM:       15440 B        16 KB     94.24%ITCM_FLASH:          0 GB        16 KB      0.00%
ITCM_FLASH_CONFIG:          0 GB        16 KB      0.00%ITCM_FLASH1:          0 GB       480 KB      0.00%AXIM_FLASH:        2812 B        10 KB     27.46%
AXIM_FLASH_CUSTOM_DEFAULTS:           8 B         6 KB      0.13%
AXIM_FLASH_CONFIG:          0 GB        16 KB      0.00%AXIM_FLASH1:      437141 B       480 KB     88.94%
AXIM_FLASH_CUSTOM_DEFAULTS_EXTENDED:          0 GB         0 GBDTCM_RAM:       34168 B        64 KB     52.14%SRAM1:       73880 B       176 KB     40.99%SRAM2:          0 GB        16 KB      0.00%MEMORY_B1:          0 GB         0 GBtext    data     bss     dec     hex filename432557    7404  100652  540613   83fc5 ./obj/main/betaflight_STM32F7X2.elf
Creating HEX ./obj/betaflight_4.4.0_STM32F7X2.hex
make[2]: Leaving directory '/home/daniel/Work/betaflight'
make[1]: Leaving directory '/home/daniel/Work/betaflight'
Building STM32F7X2 succeeded.

此时已经生成./obj/betaflight_4.4.0_STM32F7X2.hex固件，可以采用configurator进行烧录。

Step 7 目标固件清理

有的时候可能调整了配置，甚至改动了代码，不采用增量式编译(防止有些改动没有起到效果)而希望全新编译固件。

$ make STM32F7X2_clean
make -j TARGET=STM32F7X2 clean
make[1]: Entering directory '/home/daniel/Work/betaflight'
Cleaning STM32F7X2
rm -f ./obj/betaflight_4.4.0_STM32F7X2.bin ./obj/betaflight_4.4.0_STM32F7X2_56373817f.hex ./obj/betaflight_4.4.0_STM32F7X2.hex ./obj/main/betaflight_STM32F7X2.elf ./obj/main/STM32F7X2/startup_stm32f722xx.o ./obj/main/STM32F7X2/startup/system_stm32f7xx.o ./obj/main/STM32F7X2/drivers/accgyro/accgyro_mpu.o ./obj/main/STM32F7X2/drivers/adc_stm32f7xx.o ./obj/main/STM32F7X2/drivers/audio_stm32f7xx.o ./obj/main/STM32F7X2/drivers/bus_i2c_hal.o ./obj/main/STM32F7X2/drivers/bus_i2c_hal_init.o ./obj/main/STM32F7X2/drivers/bus_i2c_timing.o ./obj/main/STM32F7X2/drivers/dma_stm32f7xx.o ./obj/main/STM32F7X2/drivers/light_ws2811strip_hal.o ./obj/main/STM32F7X2/drivers/transponder_ir_io_hal.o ./obj/main/STM32F7X2/drivers/bus_spi_ll.o ./obj/main/STM32F7X2/drivers/persistent.o ./obj/main/STM32F7X2/drivers/dshot_bitbang.o ./obj/main/STM32F7X2/drivers/dshot_bitbang_decode.o ./obj/main/STM32F7X2/drivers/dshot_bitbang_ll.o ./obj/main/STM32F7X2/drivers/pwm_output_dshot_hal.o ./obj/main/STM32F7X2/drivers/pwm_output_dshot_shared.o ./obj/main/STM32F7X2/drivers/timer_hal.o ./obj/main/STM32F7X2/drivers/timer_stm32f7xx.o ./obj/main/STM32F7X2/drivers/system_stm32f7xx.o ./obj/main/STM32F7X2/drivers/serial_uart_hal.o ./obj/main/STM32F7X2/drivers/serial_uart_stm32f7xx.o ./obj/main/STM32F7X2/drivers/sdio_f7xx.o ./obj/main/STM32F7X2/drivers/accgyro/accgyro_spi_lsm6dso_init.o ./obj/main/STM32F7X2/drivers/accgyro/accgyro_spi_icm20689.o ./obj/main/STM32F7X2/drivers/accgyro/accgyro_mpu6050.o ./obj/main/STM32F7X2/drivers/accgyro/accgyro_spi_lsm6dso.o ./obj/main/STM32F7X2/drivers/accgyro/accgyro_mpu3050.o ./obj/main/STM32F7X2/drivers/accgyro/accgyro_spi_l3gd20.o ./obj/main/STM32F7X2/drivers/accgyro/accgyro_spi_icm20649.o ./obj/main/STM32F7X2/drivers/accgyro/accgyro_mpu.o ./obj/main/STM32F7X2/drivers/accgyro/accgyro_fake.o ./obj/main/STM32F7X2/drivers/accgyro/accgyro_spi_icm426xx.o ./obj/main/STM32F7X2/drivers/accgyro/gyro_sync.o ./obj/main/STM32F7X2/drivers/accgyro/accgyro_spi_bmi270.o ./obj/main/STM32F7X2/drivers/accgyro/accgyro_spi_mpu6500.o ./obj/main/STM32F7X2/drivers/accgyro/accgyro_spi_mpu9250.o ./obj/main/STM32F7X2/drivers/accgyro/accgyro_spi_bmi160.o ./obj/main/STM32F7X2/drivers/accgyro/accgyro_spi_mpu6000.o ./obj/main/STM32F7X2/drivers/accgyro/accgyro_mpu6500.o ./obj/main/STM32F7X2/./lib/main/BoschSensortec/BMI270-Sensor-API/bmi270_maximum_fifo.o ./obj/main/STM32F7X2/drivers/barometer/barometer_bmp085.o ./obj/main/STM32F7X2/drivers/barometer/barometer_ms5611.o ./obj/main/STM32F7X2/drivers/barometer/barometer_qmp6988.o ./obj/main/STM32F7X2/drivers/barometer/barometer_2smpb_02b.o ./obj/main/STM32F7X2/drivers/barometer/barometer_lps.o ./obj/main/STM32F7X2/drivers/barometer/barometer_dps310.o ./obj/main/STM32F7X2/drivers/barometer/barometer_fake.o ./obj/main/STM32F7X2/drivers/barometer/barometer_bmp388.o ./obj/main/STM32F7X2/drivers/barometer/barometer_bmp280.o ./obj/main/STM32F7X2/drivers/compass/compass_mpu925x_ak8963.o ./obj/main/STM32F7X2/drivers/compass/compass_lis3mdl.o ./obj/main/STM32F7X2/drivers/compass/compass_ak8963.o ./obj/main/STM32F7X2/drivers/compass/compass_ak8975.o ./obj/main/STM32F7X2/drivers/compass/compass_hmc5883l.o ./obj/main/STM32F7X2/drivers/compass/compass_fake.o ./obj/main/STM32F7X2/drivers/compass/compass_qmc5883l.o ./obj/main/STM32F7X2/drivers/max7456.o ./obj/main/STM32F7X2/drivers/vtx_rtc6705.o ./obj/main/STM32F7X2/drivers/vtx_rtc6705_soft_spi.o ./obj/main/STM32F7X2/rx/cc2500_common.o ./obj/main/STM32F7X2/rx/cc2500_frsky_shared.o ./obj/main/STM32F7X2/rx/cc2500_frsky_d.o ./obj/main/STM32F7X2/rx/cc2500_frsky_x.o ./obj/main/STM32F7X2/rx/cc2500_sfhss.o ./obj/main/STM32F7X2/rx/cc2500_redpine.o ./obj/main/STM32F7X2/rx/a7105_flysky.o ./obj/main/STM32F7X2/rx/cyrf6936_spektrum.o ./obj/main/STM32F7X2/drivers/rx/expresslrs_driver.o ./obj/main/STM32F7X2/rx/expresslrs.o ./obj/main/STM32F7X2/rx/expresslrs_common.o ./obj/main/STM32F7X2/rx/expresslrs_telemetry.o ./obj/main/STM32F7X2/drivers/rx/rx_cc2500.o ./obj/main/STM32F7X2/drivers/rx/rx_a7105.o ./obj/main/STM32F7X2/drivers/rx/rx_cyrf6936.o ./obj/main/STM32F7X2/drivers/rx/rx_sx127x.o ./obj/main/STM32F7X2/drivers/rx/rx_sx1280.o ./obj/main/STM32F7X2/./lib/main/CMSIS/DSP/Source/TransformFunctions/arm_bitreversal2.o ./obj/main/STM32F7X2/drivers/flash.o ./obj/main/STM32F7X2/drivers/flash_m25p16.o ./obj/main/STM32F7X2/drivers/flash_w25n01g.o ./obj/main/STM32F7X2/drivers/flash_w25q128fv.o ./obj/main/STM32F7X2/drivers/flash_w25m.o ./obj/main/STM32F7X2/io/flashfs.o ./obj/main/STM32F7X2/drivers/usb_msc_common.o ./obj/main/STM32F7X2/drivers/usb_msc_f7xx.o ./obj/main/STM32F7X2/msc/usbd_storage.o ./obj/main/STM32F7X2/msc/usbd_storage_sdio.o ./obj/main/STM32F7X2/msc/usbd_storage_sd_spi.o ./obj/main/STM32F7X2/msc/usbd_storage_emfat.o ./obj/main/STM32F7X2/msc/emfat.o ./obj/main/STM32F7X2/msc/emfat_file.o ./obj/main/STM32F7X2/build/build_config.o ./obj/main/STM32F7X2/build/debug.o ./obj/main/STM32F7X2/build/debug_pin.o ./obj/main/STM32F7X2/build/version.o ./obj/main/STM32F7X2/target.o ./obj/main/STM32F7X2/main.o ./obj/main/STM32F7X2/pg/rx_spi_cc2500.o ./obj/main/STM32F7X2/pg/motor.o ./obj/main/STM32F7X2/pg/rcdevice.o ./obj/main/STM32F7X2/pg/pg.o ./obj/main/STM32F7X2/pg/pin_pull_up_down.o ./obj/main/STM32F7X2/pg/bus_i2c.o ./obj/main/STM32F7X2/pg/bus_spi.o ./obj/main/STM32F7X2/pg/vcd.o ./obj/main/STM32F7X2/pg/dyn_notch.o ./obj/main/STM32F7X2/pg/pinio.o ./obj/main/STM32F7X2/pg/beeper_dev.o ./obj/main/STM32F7X2/pg/rpm_filter.o ./obj/main/STM32F7X2/pg/vtx_io.o ./obj/main/STM32F7X2/pg/board.o ./obj/main/STM32F7X2/pg/rx.o ./obj/main/STM32F7X2/pg/scheduler.o ./obj/main/STM32F7X2/pg/adc.o ./obj/main/STM32F7X2/pg/dashboard.o ./obj/main/STM32F7X2/pg/displayport_profiles.o ./obj/main/STM32F7X2/pg/rx_spi.o ./obj/main/STM32F7X2/pg/timerup.o ./obj/main/STM32F7X2/pg/gps.o ./obj/main/STM32F7X2/pg/vtx_table.o ./obj/main/STM32F7X2/pg/gps_rescue.o ./obj/main/STM32F7X2/pg/flash.o ./obj/main/STM32F7X2/pg/rx_pwm.o ./obj/main/STM32F7X2/pg/mco.o ./obj/main/STM32F7X2/pg/beeper.o ./obj/main/STM32F7X2/pg/usb.o ./obj/main/STM32F7X2/pg/bus_quadspi.o ./obj/main/STM32F7X2/pg/timerio.o ./obj/main/STM32F7X2/pg/max7456.o ./obj/main/STM32F7X2/pg/stats.o ./obj/main/STM32F7X2/pg/rx_spi_expresslrs.o ./obj/main/STM32F7X2/pg/piniobox.o ./obj/main/STM32F7X2/pg/sdcard.o ./obj/main/STM32F7X2/pg/serial_uart.o ./obj/main/STM32F7X2/pg/gyrodev.o ./obj/main/STM32F7X2/pg/msp.o ./obj/main/STM32F7X2/pg/sdio.o ./obj/main/STM32F7X2/common/maths.o ./obj/main/STM32F7X2/common/bitarray.o ./obj/main/STM32F7X2/common/strtol.o ./obj/main/STM32F7X2/common/crc.o ./obj/main/STM32F7X2/common/huffman.o ./obj/main/STM32F7X2/common/uvarint.o ./obj/main/STM32F7X2/common/time.o ./obj/main/STM32F7X2/common/sdft.o ./obj/main/STM32F7X2/common/typeconversion.o ./obj/main/STM32F7X2/common/string_light.o ./obj/main/STM32F7X2/common/huffman_table.o ./obj/main/STM32F7X2/common/encoding.o ./obj/main/STM32F7X2/common/printf_serial.o ./obj/main/STM32F7X2/common/filter.o ./obj/main/STM32F7X2/common/sensor_alignment.o ./obj/main/STM32F7X2/common/explog_approx.o ./obj/main/STM32F7X2/common/gps_conversion.o ./obj/main/STM32F7X2/common/streambuf.o ./obj/main/STM32F7X2/common/printf.o ./obj/main/STM32F7X2/common/colorconversion.o ./obj/main/STM32F7X2/config/config_eeprom.o ./obj/main/STM32F7X2/config/simplified_tuning.o ./obj/main/STM32F7X2/config/config.o ./obj/main/STM32F7X2/config/config_streamer.o ./obj/main/STM32F7X2/config/feature.o ./obj/main/STM32F7X2/cli/cli.o ./obj/main/STM32F7X2/cli/settings.o ./obj/main/STM32F7X2/config/config.o ./obj/main/STM32F7X2/drivers/adc.o ./obj/main/STM32F7X2/drivers/dshot.o ./obj/main/STM32F7X2/drivers/dshot_dpwm.o ./obj/main/STM32F7X2/drivers/dshot_command.o ./obj/main/STM32F7X2/drivers/buf_writer.o ./obj/main/STM32F7X2/drivers/bus.o ./obj/main/STM32F7X2/drivers/bus_i2c_config.o ./obj/main/STM32F7X2/drivers/bus_i2c_busdev.o ./obj/main/STM32F7X2/drivers/bus_i2c_soft.o ./obj/main/STM32F7X2/drivers/bus_quadspi.o ./obj/main/STM32F7X2/drivers/bus_spi.o ./obj/main/STM32F7X2/drivers/bus_spi_config.o ./obj/main/STM32F7X2/drivers/bus_spi_pinconfig.o ./obj/main/STM32F7X2/drivers/buttons.o ./obj/main/STM32F7X2/drivers/display.o ./obj/main/STM32F7X2/drivers/display_canvas.o ./obj/main/STM32F7X2/drivers/dma_common.o ./obj/main/STM32F7X2/drivers/dma_reqmap.o ./obj/main/STM32F7X2/drivers/exti.o ./obj/main/STM32F7X2/drivers/io.o ./obj/main/STM32F7X2/drivers/light_led.o ./obj/main/STM32F7X2/drivers/mco.o ./obj/main/STM32F7X2/drivers/motor.o ./obj/main/STM32F7X2/drivers/pinio.o ./obj/main/STM32F7X2/drivers/pin_pull_up_down.o ./obj/main/STM32F7X2/drivers/resource.o ./obj/main/STM32F7X2/drivers/rcc.o ./obj/main/STM32F7X2/drivers/serial.o ./obj/main/STM32F7X2/drivers/serial_pinconfig.o ./obj/main/STM32F7X2/drivers/serial_uart.o ./obj/main/STM32F7X2/drivers/serial_uart_pinconfig.o ./obj/main/STM32F7X2/drivers/sound_beeper.o ./obj/main/STM32F7X2/drivers/stack_check.o ./obj/main/STM32F7X2/drivers/system.o ./obj/main/STM32F7X2/drivers/timer_common.o ./obj/main/STM32F7X2/drivers/transponder_ir_arcitimer.o ./obj/main/STM32F7X2/drivers/transponder_ir_ilap.o ./obj/main/STM32F7X2/drivers/transponder_ir_erlt.o ./obj/main/STM32F7X2/fc/board_info.o ./obj/main/STM32F7X2/fc/dispatch.o ./obj/main/STM32F7X2/fc/hardfaults.o ./obj/main/STM32F7X2/fc/tasks.o ./obj/main/STM32F7X2/fc/runtime_config.o ./obj/main/STM32F7X2/fc/stats.o ./obj/main/STM32F7X2/io/beeper.o ./obj/main/STM32F7X2/io/piniobox.o ./obj/main/STM32F7X2/io/serial.o ./obj/main/STM32F7X2/io/smartaudio_protocol.o ./obj/main/STM32F7X2/io/statusindicator.o ./obj/main/STM32F7X2/io/tramp_protocol.o ./obj/main/STM32F7X2/io/transponder_ir.o ./obj/main/STM32F7X2/io/usb_cdc_hid.o ./obj/main/STM32F7X2/io/usb_msc.o ./obj/main/STM32F7X2/msp/msp.o ./obj/main/STM32F7X2/msp/msp_box.o ./obj/main/STM32F7X2/msp/msp_serial.o ./obj/main/STM32F7X2/scheduler/scheduler.o ./obj/main/STM32F7X2/sensors/adcinternal.o ./obj/main/STM32F7X2/sensors/battery.o ./obj/main/STM32F7X2/sensors/current.o ./obj/main/STM32F7X2/sensors/voltage.o ./obj/main/STM32F7X2/target/config_helper.o ./obj/main/STM32F7X2/fc/init.o ./obj/main/STM32F7X2/fc/controlrate_profile.o ./obj/main/STM32F7X2/drivers/camera_control.o ./obj/main/STM32F7X2/drivers/accgyro/gyro_sync.o ./obj/main/STM32F7X2/drivers/pwm_esc_detect.o ./obj/main/STM32F7X2/drivers/pwm_output.o ./obj/main/STM32F7X2/drivers/rx/rx_spi.o ./obj/main/STM32F7X2/drivers/rx/rx_xn297.o ./obj/main/STM32F7X2/drivers/rx/rx_pwm.o ./obj/main/STM32F7X2/drivers/serial_softserial.o ./obj/main/STM32F7X2/fc/core.o ./obj/main/STM32F7X2/fc/rc.o ./obj/main/STM32F7X2/fc/rc_adjustments.o ./obj/main/STM32F7X2/fc/rc_controls.o ./obj/main/STM32F7X2/fc/rc_modes.o ./obj/main/STM32F7X2/flight/position.o ./obj/main/STM32F7X2/flight/failsafe.o ./obj/main/STM32F7X2/flight/gps_rescue.o ./obj/main/STM32F7X2/flight/dyn_notch_filter.o ./obj/main/STM32F7X2/flight/imu.o ./obj/main/STM32F7X2/flight/feedforward.o ./obj/main/STM32F7X2/flight/mixer.o ./obj/main/STM32F7X2/flight/mixer_init.o ./obj/main/STM32F7X2/flight/mixer_tricopter.o ./obj/main/STM32F7X2/flight/pid.o ./obj/main/STM32F7X2/flight/pid_init.o ./obj/main/STM32F7X2/flight/rpm_filter.o ./obj/main/STM32F7X2/flight/servos.o ./obj/main/STM32F7X2/flight/servos_tricopter.o ./obj/main/STM32F7X2/io/serial_4way.o ./obj/main/STM32F7X2/io/serial_4way_avrootloader.o ./obj/main/STM32F7X2/io/serial_4way_stk500v2.o ./obj/main/STM32F7X2/rx/ibus.o ./obj/main/STM32F7X2/rx/jetiexbus.o ./obj/main/STM32F7X2/rx/msp.o ./obj/main/STM32F7X2/rx/pwm.o ./obj/main/STM32F7X2/rx/frsky_crc.o ./obj/main/STM32F7X2/rx/rx.o ./obj/main/STM32F7X2/rx/rx_bind.o ./obj/main/STM32F7X2/rx/rx_spi.o ./obj/main/STM32F7X2/rx/rx_spi_common.o ./obj/main/STM32F7X2/rx/crsf.o ./obj/main/STM32F7X2/rx/ghst.o ./obj/main/STM32F7X2/rx/sbus.o ./obj/main/STM32F7X2/rx/sbus_channels.o ./obj/main/STM32F7X2/rx/spektrum.o ./obj/main/STM32F7X2/rx/srxl2.o ./obj/main/STM32F7X2/io/spektrum_vtx_control.o ./obj/main/STM32F7X2/io/spektrum_rssi.o ./obj/main/STM32F7X2/rx/sumd.o ./obj/main/STM32F7X2/rx/sumh.o ./obj/main/STM32F7X2/rx/xbus.o ./obj/main/STM32F7X2/rx/fport.o ./obj/main/STM32F7X2/rx/msp_override.o ./obj/main/STM32F7X2/sensors/acceleration.o ./obj/main/STM32F7X2/sensors/acceleration_init.o ./obj/main/STM32F7X2/sensors/boardalignment.o ./obj/main/STM32F7X2/sensors/compass.o ./obj/main/STM32F7X2/sensors/gyro.o ./obj/main/STM32F7X2/sensors/gyro_init.o ./obj/main/STM32F7X2/sensors/initialisation.o ./obj/main/STM32F7X2/blackbox/blackbox.o ./obj/main/STM32F7X2/blackbox/blackbox_encoding.o ./obj/main/STM32F7X2/blackbox/blackbox_io.o ./obj/main/STM32F7X2/cms/cms.o ./obj/main/STM32F7X2/cms/cms_menu_blackbox.o ./obj/main/STM32F7X2/cms/cms_menu_failsafe.o ./obj/main/STM32F7X2/cms/cms_menu_firmware.o ./obj/main/STM32F7X2/cms/cms_menu_gps_rescue.o ./obj/main/STM32F7X2/cms/cms_menu_imu.o ./obj/main/STM32F7X2/cms/cms_menu_ledstrip.o ./obj/main/STM32F7X2/cms/cms_menu_main.o ./obj/main/STM32F7X2/cms/cms_menu_misc.o ./obj/main/STM32F7X2/cms/cms_menu_osd.o ./obj/main/STM32F7X2/cms/cms_menu_power.o ./obj/main/STM32F7X2/cms/cms_menu_saveexit.o ./obj/main/STM32F7X2/cms/cms_menu_vtx_common.o ./obj/main/STM32F7X2/cms/cms_menu_vtx_rtc6705.o ./obj/main/STM32F7X2/cms/cms_menu_vtx_smartaudio.o ./obj/main/STM32F7X2/cms/cms_menu_vtx_tramp.o ./obj/main/STM32F7X2/cms/cms_menu_persistent_stats.o ./obj/main/STM32F7X2/drivers/display_ug2864hsweg01.o ./obj/main/STM32F7X2/drivers/light_ws2811strip.o ./obj/main/STM32F7X2/drivers/rangefinder/rangefinder_hcsr04.o ./obj/main/STM32F7X2/drivers/rangefinder/rangefinder_lidartf.o ./obj/main/STM32F7X2/drivers/serial_escserial.o ./obj/main/STM32F7X2/drivers/vtx_common.o ./obj/main/STM32F7X2/drivers/vtx_table.o ./obj/main/STM32F7X2/io/dashboard.o ./obj/main/STM32F7X2/io/displayport_frsky_osd.o ./obj/main/STM32F7X2/io/displayport_max7456.o ./obj/main/STM32F7X2/io/displayport_msp.o ./obj/main/STM32F7X2/io/displayport_oled.o ./obj/main/STM32F7X2/io/displayport_srxl.o ./obj/main/STM32F7X2/io/displayport_crsf.o ./obj/main/STM32F7X2/io/displayport_hott.o ./obj/main/STM32F7X2/io/frsky_osd.o ./obj/main/STM32F7X2/io/rcdevice_cam.o ./obj/main/STM32F7X2/io/rcdevice.o ./obj/main/STM32F7X2/io/gps.o ./obj/main/STM32F7X2/io/ledstrip.o ./obj/main/STM32F7X2/io/pidaudio.o ./obj/main/STM32F7X2/osd/osd.o ./obj/main/STM32F7X2/osd/osd_elements.o ./obj/main/STM32F7X2/osd/osd_warnings.o ./obj/main/STM32F7X2/sensors/barometer.o ./obj/main/STM32F7X2/sensors/rangefinder.o ./obj/main/STM32F7X2/telemetry/telemetry.o ./obj/main/STM32F7X2/telemetry/crsf.o ./obj/main/STM32F7X2/telemetry/ghst.o ./obj/main/STM32F7X2/telemetry/srxl.o ./obj/main/STM32F7X2/telemetry/frsky_hub.o ./obj/main/STM32F7X2/telemetry/hott.o ./obj/main/STM32F7X2/telemetry/jetiexbus.o ./obj/main/STM32F7X2/telemetry/smartport.o ./obj/main/STM32F7X2/telemetry/ltm.o ./obj/main/STM32F7X2/telemetry/mavlink.o ./obj/main/STM32F7X2/telemetry/msp_shared.o ./obj/main/STM32F7X2/telemetry/ibus.o ./obj/main/STM32F7X2/telemetry/ibus_shared.o ./obj/main/STM32F7X2/sensors/esc_sensor.o ./obj/main/STM32F7X2/io/vtx.o ./obj/main/STM32F7X2/io/vtx_rtc6705.o ./obj/main/STM32F7X2/io/vtx_smartaudio.o ./obj/main/STM32F7X2/io/vtx_tramp.o ./obj/main/STM32F7X2/io/vtx_control.o ./obj/main/STM32F7X2/io/vtx_msp.o ./obj/main/STM32F7X2/cms/cms_menu_vtx_msp.o ./obj/main/STM32F7X2/stm32f7xx_hal_cortex.o ./obj/main/STM32F7X2/stm32f7xx_ll_rcc.o ./obj/main/STM32F7X2/stm32f7xx_hal_uart_ex.o ./obj/main/STM32F7X2/stm32f7xx_hal_dac_ex.o ./obj/main/STM32F7X2/stm32f7xx_hal.o ./obj/main/STM32F7X2/stm32f7xx_hal_adc.o ./obj/main/STM32F7X2/stm32f7xx_hal_pwr.o ./obj/main/STM32F7X2/stm32f7xx_hal_flash_ex.o ./obj/main/STM32F7X2/stm32f7xx_hal_flash.o ./obj/main/STM32F7X2/stm32f7xx_hal_spi_ex.o ./obj/main/STM32F7X2/stm32f7xx_hal_tim_ex.o ./obj/main/STM32F7X2/stm32f7xx_hal_pcd.o ./obj/main/STM32F7X2/stm32f7xx_hal_dma_ex.o ./obj/main/STM32F7X2/stm32f7xx_hal_rcc.o ./obj/main/STM32F7X2/stm32f7xx_ll_utils.o ./obj/main/STM32F7X2/stm32f7xx_ll_dma2d.o ./obj/main/STM32F7X2/stm32f7xx_hal_rtc_ex.o ./obj/main/STM32F7X2/stm32f7xx_ll_spi.o ./obj/main/STM32F7X2/stm32f7xx_ll_gpio.o ./obj/main/STM32F7X2/stm32f7xx_hal_i2c_ex.o ./obj/main/STM32F7X2/stm32f7xx_hal_usart.o ./obj/main/STM32F7X2/stm32f7xx_hal_pwr_ex.o ./obj/main/STM32F7X2/stm32f7xx_hal_rcc_ex.o ./obj/main/STM32F7X2/stm32f7xx_hal_uart.o ./obj/main/STM32F7X2/stm32f7xx_ll_dma.o ./obj/main/STM32F7X2/stm32f7xx_hal_dma.o ./obj/main/STM32F7X2/stm32f7xx_hal_exti.o ./obj/main/STM32F7X2/stm32f7xx_ll_usb.o ./obj/main/STM32F7X2/stm32f7xx_hal_tim.o ./obj/main/STM32F7X2/stm32f7xx_hal_pcd_ex.o ./obj/main/STM32F7X2/stm32f7xx_hal_spi.o ./obj/main/STM32F7X2/stm32f7xx_hal_gpio.o ./obj/main/STM32F7X2/stm32f7xx_hal_dac.o ./obj/main/STM32F7X2/stm32f7xx_hal_i2c.o ./obj/main/STM32F7X2/stm32f7xx_hal_rtc.o ./obj/main/STM32F7X2/stm32f7xx_ll_tim.o ./obj/main/STM32F7X2/stm32f7xx_hal_adc_ex.o ./obj/main/STM32F7X2/usbd_core.o ./obj/main/STM32F7X2/usbd_ctlreq.o ./obj/main/STM32F7X2/usbd_ioreq.o ./obj/main/STM32F7X2/usbd_cdc.o ./obj/main/STM32F7X2/usbd_hid.o ./obj/main/STM32F7X2/usbd_msc.o ./obj/main/STM32F7X2/usbd_msc_bot.o ./obj/main/STM32F7X2/usbd_msc_data.o ./obj/main/STM32F7X2/usbd_msc_scsi.o ./obj/main/STM32F7X2/drivers/sdcard.o ./obj/main/STM32F7X2/drivers/sdcard_spi.o ./obj/main/STM32F7X2/drivers/sdcard_standard.o ./obj/main/STM32F7X2/io/asyncfatfs/asyncfatfs.o ./obj/main/STM32F7X2/io/asyncfatfs/fat_standard.o ./obj/main/STM32F7X2/drivers/usb_msc_common.o ./obj/main/STM32F7X2/drivers/usb_msc_f7xx.o ./obj/main/STM32F7X2/msc/usbd_storage.o ./obj/main/STM32F7X2/msc/usbd_storage_sdio.o ./obj/main/STM32F7X2/msc/usbd_storage_sd_spi.o ./obj/main/STM32F7X2/msc/usbd_storage_emfat.o ./obj/main/STM32F7X2/msc/emfat.o ./obj/main/STM32F7X2/msc/emfat_file.o ./obj/main/STM32F7X2/drivers/sdcard.o ./obj/main/STM32F7X2/drivers/sdcard_sdio_baremetal.o ./obj/main/STM32F7X2/drivers/sdcard_standard.o ./obj/main/STM32F7X2/io/asyncfatfs/asyncfatfs.o ./obj/main/STM32F7X2/io/asyncfatfs/fat_standard.o ./obj/main/STM32F7X2/drivers/usb_msc_common.o ./obj/main/STM32F7X2/drivers/usb_msc_f7xx.o ./obj/main/STM32F7X2/msc/usbd_storage.o ./obj/main/STM32F7X2/msc/usbd_storage_sdio.o ./obj/main/STM32F7X2/msc/usbd_storage_sd_spi.o ./obj/main/STM32F7X2/msc/usbd_storage_emfat.o ./obj/main/STM32F7X2/msc/emfat.o ./obj/main/STM32F7X2/msc/emfat_file.o ./obj/main/STM32F7X2/vcp_hal/usbd_desc.o ./obj/main/STM32F7X2/vcp_hal/usbd_conf_stm32f7xx.o ./obj/main/STM32F7X2/vcp_hal/usbd_cdc_hid.o ./obj/main/STM32F7X2/vcp_hal/usbd_cdc_interface.o ./obj/main/STM32F7X2/drivers/serial_usb_vcp.o ./obj/main/STM32F7X2/drivers/usb_io.o ./obj/main/STM32F7X2/./lib/main/google/olc/olc.o ./obj/main/betaflight_STM32F7X2.map ./obj/main/betaflight_STM32F7X2.lst ./obj/betaflight_4.4.0_STM32F7X2.dfu
rm -rf ./obj/main/STM32F7X2
Cleaning STM32F7X2 succeeded.
make[1]: Leaving directory '/home/daniel/Work/betaflight'

当clean结束后，再进行固件编译。

3. 参考资料

【1】Github BetaFlight

查看全文中文繁体

本文来自互联网用户投稿，该文观点仅代表作者本人，不代表本站立场。本站仅提供信息存储空间服务，不拥有所有权，不承担相关法律责任。如若转载，请注明出处：http://www.exyb.cn/news/show-4496536.html

如若内容造成侵权/违法违规/事实不符，请联系我们进行投诉反馈，一经查实，立即删除！

淘宝php高级工程师，内部笔记

1.在做二岸快捷的自定义导航栏时，使用 foreach(array_intersect(array_keys($menu),$user) as $key>$value){ 浪费了我近1小时，原因在于，二者取交集时 $menuAuth1,99,101, 110, 120,130,199;这类数组是不会被很好的理解 2.屏蔽变量提示错…...

编程日记 2023/3/20 23:39:36

python批量合并excel文件，后缀名为xls

最近处理的一个项目需要用到批量合并excel表格，我就用python拼了一个代码，可以实现传入一个根目录，然后将该目录下所有的后缀名为xls的excel表格进行合并，将结果输出在根目录下第三方库配置 pip install xlwd pip install pand…...

编程日记 2023/3/20 23:39:34

Serializable

最近在阅读JDK源码中的集合，看到很多集合类实现了Serializable接口,Cloneable接口。在阅读了很多关于Serializable接口的博客后，浅谈下我对Serializable接口的理解。序列化查看官方文档就会发现 Serializable接口中一个成员函数或者成员变量也没有。那么这个接口的作用是…...

编程日记 2023/3/20 23:39:31

video+src+html,HTML video src 属性 | 菜鸟教程

HTML src 属性实例播放一个视频：您的浏览器不支持 video 标签。尝试一下浏览器支持所有主流浏览器都支持 src 属性。但是定义的文件格式并不是所有浏览器都支持。注意： Internet Explorer 8 及更早IE版本不支持标签。定义和用法src 属性指定 video 文件…...

编程日记 2023/3/20 23:39:28

flash倒计时功能

EndTimenew Date(2008,1,19,0,0,0);//定义倒计时结束时间，此处为2008北京奥运开幕日 //注意，月份参数用0-11表示1-12月 NowTimenew Date();//定义当前时间 zongMath.floor((EndTime.getTime()-NowTime.getTime())/1000);//取得当前时间与结束时间相差…...

编程日记 2023/3/20 23:39:28

mac使用Homebrew安装node

记录自己在使用mac安装npm过程中出现的问题并如何解决的一、安装brew Homebrew安装apple或linux系统没有预装但需要的东西原始命令： /bin/bash -c "$(curl -fsSL https://raw.githubusercontent.com/Homebrew/install/HEAD/install.sh)"安装速度很慢&a…...

编程日记 2023/3/20 23:39:27

Visual Studio查看元数据以源代码形式显示

简介当人员进行项目开发时，经常需要查看他们在代码中所使用的类型或类成员的源代码定义。在 Visual Studio 中，经常使用 “转到定义”和“速览定义” 查看类型或成员的定义。如果源代码不可用，则会显示为元数据。常规 F12 使用 Visu…...

编程日记 2023/3/20 23:39:25

评估指标nlg-eval安装包踩坑

安装包说明：https://github.com/Maluuba/nlg-eval 1、nlg-eval包安装：下载安装包后，命令行窗口/Linux进入nlg-eval文件夹中，执行语句python setup.py install 2、安装好之后需要下载所需数据包： Linux直接执行语句&a…...

编程日记 2023/3/20 23:39:12

数据库有百万数据量的情况下，分页查询的方法及其优化方式

推荐阅读：吊打面试官！MySQL灵魂100问，你能答出多少？ 当需要从数据库查询的表有上万条记录的时候，一次性查询所有结果会变得很慢，特别是随着数据量的增加特别明显，这时需要使用分页查询。对于数据…...

编程日记 2023/3/20 23:38:46

阿里P8大牛手把手教你！20道Java工程师面试必问题

一. 为什么使用spring cloud alibaba 很多人可能会问，有了spring cloud这个微服务的框架，为什么又要使用spring cloud alibaba这个框架了？ 最重要的原因在于spring cloud中的几乎所有的组件都使用Netflix公司的产品，然后在其基础…...

编程日记 2023/3/20 23:38:43

flash倒计时制作

1.启动Flash，新建元件，命名为“倒计时”，行为中选择“影片剪辑”，确定后进入元件编辑窗口。 2.点击文本工具，在属性中选择“静态文本”，划出一个文本框，设置好文本框的参数，输入…...

编程日记 2023/3/20 23:38:37

一、查看当前内核版本 $ uname -r3.10.0-693.11.6.el7.x86_64$ uname -aLinux k8s-master 3.10.0-693.11.6.el7.x86_64 #1 SMP Tue Nov 22 16:42:41 UTC 2016 x86_64 x86_64 x86_64 GNU/Linux$ cat /etc/redhat-release CentOS Linux release 7.3.1611 (Core) 2、升级内核更…...

编程日记 2023/3/20 23:38:31

Linux学习笔记---移植官方uboot步骤（一）

目录编写shell脚本修改MakeFile文件重命名shell脚本添加默认配置文件修改默认配置文件准备需要的板级文件夹重命名.C文件修改Makefile 修改imximage.cfg配置文件修改Kconfig文件修改MAINTAINERS 文件修改uboot图形配置界面编译自己的uboot 使用的开发…...

编程日记 2023/3/20 23:38:28

使用docker创建和运行跨平台的容器化的mssql数据库

我们一般启用sql server数据库要么选择安装SQL Server实例和管理工具（SSMS），要么用vs自带的数据库。如今net跨平台成为趋势，今天给大家介绍另一种我最近在玩的方式，即使用docker创建并启用sql数据库。本章介绍了在window10专业版下如何利用docker创建mssql数据库，包括以…...

编程日记 2023/3/20 23:38:24

会发光的微笑和会脸红的墙：微软实现建筑与人工智能的完美融合

Jenny Sabin 正站在高高升起的剪叉式升降机上，努力组装着她的艺术作品。这件高悬在微软雷德蒙德园区99号楼中庭的装置呈现出了多孔织物组织的构造，而 Jenny 正努力从其中的一个开口中探出头来，并试着将这个开口的织物衔接到周边的骨架上。几…...

编程日记 2023/3/20 23:38:22

Springsecurity从当前请求对象中获取用户信息

从当前请求对象中获取用户信息 RequestMapping("/authentication") public void authentication(Authentication authentication) {System.out.println("authentication " authentication); } RequestMapping("/principal") public void prin…...

编程日记 2023/3/20 23:38:20

Linux CentOS7 简单了解

（一）什么是Linux。 Linux是一套免费使用和自由传播的类Unix操作系统。UNIX操作系统是一个强大的多用户、多任务操作系统，支持多种处理器架构，最早由KenThompson于1969年在贝尔实验室开发。Linux是Unix的开源实现，Unix一…...

编程日记 2023/3/20 23:38:19

mongo1的5个配置文件

前言：这是文章<<单机搭建mongo集群，3个分片集>>配套配置文件链接：https://editor.csdn.net/md?articleId120353582 cd /data/mongo1/confmongo1 配置节点的配置文件 [rootnode4 conf]# cat configsvr.conf systemLog:destin…...

编程日记 2023/3/20 23:38:19

Base64 编码知识，一文打尽！

现在网站为了提升用户的浏览体验越来越多的使用了图片，而这些图片通常以 Base64 的形式存储和加载。因此各位开发工程师肯定对 Base64 毫不陌生了，那么你知道 Base64 究竟是什么，为什么要使用 Base64，以及 Base64 的优缺点吗？什么是 Base64 Base64 是网络中存储和传输的二…...

编程日记 2023/3/20 23:38:16

oracle11g的生产环境,Oracle11grac生产环境部署详录

Oracle 11g rac 生产环境部署详录作者：田逸( sery163.com ) 基本规划 ◎ 设备选型 1 、服务器： Dell R620 两台。 cpu 8 core ，内存 64G ， 600G 15000 转 sas 硬盘，双电源， hba 卡一块，连接存储…...

编程日记 2023/3/20 23:38:14

kubespray安装高可用k8s集群

kubespray快速安装高可用k8s集群 Kubespray 简介 Kubespray (opens new window)是 Kubernetes incubator 中的项目，目标是提供 Production Ready Kubernetes 部署方案，该项目基础是通过 Ansible Playbook 来定义系统与 Kubernetes 集群部署的任务&#…...

编程日记 2023/3/20 23:38:07

前端性能优化手段

前端性能优化分为两类：一类是文件加载更快：减少请求资源的大小：图片压缩和文件压缩减少网络请求次数：雪碧图(精灵图)、防抖和节流减少渲染次数：HTTP缓存、本地缓存(sessionStorage、localStorage)、Vue中的keep-alive缓存一类是文件渲染更快：提前渲染：ssr服务端渲…...

编程日记 2023/3/20 23:38:04

win10电子邮件没有关联_我们如何为在线课程建立10K电子邮件列表

win10电子邮件没有关联One year ago we launched our very first free coding course on Scrimba.com, an online learning platform which Sindre Aarsther and I have co-founded. The course was about CSS Grid and it was highly anticipated, as we had built a waiting …...

编程日记 2023/3/20 23:38:01

高级PHP工程师所应该具备的一些技能

一、平静的心态和所有程序员一样，要写一手好的程序，没有好的心态是不行的。遇事不可急躁，不可轻言放弃。在程序开发过程中，尤其是初中级程序员，写出的程序或架构会遇到很多问题，其中一些问题比较弱智…...

编程日记 2023/3/20 23:37:59

pyhton---二分查找

一，定义二分搜索是一种在有序数组中查找某一特定元素的搜索算法。搜索过程从数组的中间元素开始，如果中间元素正好是要查找的元素，则搜索过程结束；如果某一特定元素大于或者小于中间元素，则在数组大于或小于中间元素…...

编程日记 2023/3/20 23:37:56

Seata源码分析(一). AT模式底层实现

目录GlobalTransactionScanner继承AbstractAutoProxyCreator实现InitializingBean接口写在最后以AT为例，我们使用Seata时只需要在全局事务的方法上加上@GlobalTransactional，就开启了全局事务的支持。那么Seata的底层到底是怎么实现的呢？首先我们知道，Seata也是一个Sprin…...

编程日记 2023/3/20 23:37:52

树莓派3B+安装Android 10系统

Android Things 作为 Google 旗下的一款操作系统 (OS)，能够帮助开发者规模化开发和维护物联网设备。同时推出的 Android Things 控制台 (Android Things Console) 更是将简化产品开发推向极致，帮助开发者定期获取 Google 最新稳定性修复包以及安全升级包…...

编程日记 2023/3/20 23:37:52

三个点拟合圆形的函数C#

三个点拟合圆形的函数函数说明 public void FitCircleFromThreePoints(double 点1X, double 点1Y, double 点2X, double 点2Y, double 点3X, double 点3Y, out double 圆心X坐标, out double 圆心Y坐标, out double 圆形半径大小)public void FitCircleFromThreePoints(doub…...

编程日记 2023/3/20 23:37:50

v86.01 鸿蒙内核源码分析 (静态分配篇) | 很简单的一位小朋友 | 百篇博客分析 OpenHarmony 源码

本篇关键词：池头、池体、节头、节块内存管理相关篇为:v31.02 鸿蒙内核源码分析(内存规则) | 内存管理到底在管什么 v32.04 鸿蒙内核源码分析(物理内存) | 真实的可不一定精彩 v33.04 鸿蒙内核源码分析(内存概念) | RAM & ROM & Flash v34.03 鸿蒙内核源码分析(虚实映射…...

编程日记 2023/3/20 23:37:48

手机腾讯视频离线缓存ts格式文件合并为完整视频

写这边文章主要是记个笔记，方便日后使用。功能背景：很多老人都喜欢听戏。我爷爷突然问我能不能帮他下载点戏曲，于是我用手机帮忙搜了下，发现腾讯视频上有很多戏曲，而且也可以离线缓存，我就说可以。然而缓…...

编程日记 2023/3/20 23:37:46

python content函数_python函数内容

在刚接触python的时候就有个疑问，什么是函数？ python语言的函数和数学语言的函数有区别吗？什么是函数数学函数：给定一个数集A，假设其中的元素为x。现对A中的元素x施加对应法则f，记作f(x)，得到另…...

编程日记 2023/3/20 23:37:45

centos7安装mysql5.7.24版本

参考：文章正在审核中... - 简书 #1.先检查是否有安装过mysql rpm -e mysql #2.检查有没有安装，如有则删除 rpm -qa | grep mysql #3.卸载MariaDB 如果直接点击rpm包安装会得到错误提示。因为CentOS的默认数据库已经不再是MySQL了，而是M…...

编程日记 2023/3/20 23:37:42

判断Python输入是否是整数，字符，或浮点数

...

编程日记 2023/3/20 23:37:40

python整数因式分解

前言提示：这里可以添加本文要记录的大概内容： 对正整数进行因数分解提示：以下是本篇文章正文内容，下面案例可供参考一、因数分解是什么？ 在数学中，因数分解，又称素因数分解，是…...

编程日记 2023/3/20 23:37:37

Flash倒计时+写在自定义类+写在关键帧

目录一、链接： 一、目的 1、因为很多都有倒计时图片切换，所以我封装一个倒计时的资源，以后直接从flash赋复制，交换一下资源就可以了二、参考 1、AS3自定义事件以及发送事件（1）——发送事件三、操作…...

编程日记 2023/3/20 23:37:34

Change Buffer 只适用于非唯一索引页？错

最近在网上看到一些文章里说：“change buffer 只适用于非唯一索引页。”其实这个观点是错的，先来看看官方文档对 change buffer 的介绍：文档地址：https://dev.mysql.com/doc/refman/8.0/en/innodb-change-buffer.html The change buffer is a special data structure that…...

编程日记 2023/3/20 23:37:31

【解包裹】基于Matlab实现多聚类相位展开算法

✅作者简介：热爱科研的Matlab仿真开发者，修心和技术同步精进，matlab项目合作可私信。 🍎个人主页：Matlab科研工作室 🍊个人信条：格物致知。更多Matlab仿真内容点击👇 智能优化算法 …...

编程日记 2023/3/20 23:37:29

C++从静态类型到单例模式

详细论述C++语言中静态类型和单例模式，以及为什么会用到这个技术。目录1. 概述2. 详论2.1. 静态类型2.1.1. 静态方法成员2.1.2. 静态数据成员2.2. 单例模式2.2.1. 实现2.2.2. 问题3. 参考 1. 概述很多的知识，学习的时候理解其实并不是很深，甚至觉得是是不太必要的；而到了实…...

编程日记 2023/3/20 23:37:28

MySQL之SQL语句优化

语句优化即优化器利用自身的优化器来对我们写的SQL进行优化，然后再将其放入InnoDB引擎中执行。条件简化移除不必要的括号 select * from x where ((a = 5));上面的括号很没必要，优化器就会直接去掉。 select * from x where a = 5;等值传递 select * from x where b = a a…...

编程日记 2023/3/20 23:37:26

matlab中三点定圆,MATLAB三点确定一个圆

1 给定三个不在同一直线上的三个点的坐标，确定圆的轨迹方程234 下面是MATLAB中的函数文件5 function[a,b,c]ThreePointFitCircle(x,y,flag)6 %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%7 %Author By:Wacs58 %Date:200908139 %Email:wacs5http://www.doc…...

编程日记 2023/3/20 23:37:23

freeswitch使用mod_shout模块播放mp3

概述 freeswitch 在对VOIP语音通话中，可以通过playback命令播放IVR语音文件。默认情况下，freeswitch支持wav文件，也可以直接播放VOIP中常见编解码的G711文件、G729文件等，但是对mp3是不支持的。通过查询freeswitch的官方文档，发现mod_shout模块是可以支持MP3文件的播放。…...

编程日记 2023/3/20 23:37:20

Exynos4412 Uboot 移植 1----6

转载自http://blog.csdn.net/zqixiao_09/article/details/50805205 11111111111111111111111111111 Uboot 所用版本 u-boot-2013.01 u-boot-2013.01 中有上千文件，要想了解对于某款开发板，使用哪些文件、哪些文件首先执行、可执行文件占用内存的情况&a…...

编程日记 2023/3/20 23:37:18

c语言函数求圆面积,C语言编写函数,计算圆面积.

用c语言编写函数,求圆的周长和面积,用函数.急求.#include#definePI3.1415926doublearea(doubler){returnPI*r*r;}doubleperimeter(doubler){return2*PI*r;}iC语言程序编写函数,求圆面积的值,主函数输入半径,并在主函数中调它.#includemain(){\x09floatS(floatr);\x09floatr;\x…...

编程日记 2023/3/20 23:37:15

Hadoop进程理解

进程理解 HDFS相关进程理解（NN,DN,SSN）NameNode中存放的是数据文件与元数据的映射信息，数据文件和block快的映射信息，block块和DataNode的映射信息，前两者存放在磁盘里，Hadoop stop后不会消失，第三个存放在内存中，会消失；DataNode通过PING PONG 机制被NameNode识别，…...

编程日记 2023/3/20 23:37:08

lambda解释器_Lambda Interpreter

代码参考： 200行JS代码实现lambda解释器 PP大佬代码解释器构造一个lambda interpreter主要由一下几个方面构成： 词法分析器（Lexer）：将字符流分解为符号流（token流）语法分析器&#xff08…...

编程日记 2023/3/20 23:37:04

『忘了再学』Shell基础 — 19、使用declare命令声明变量类型

目录1、declare命令介绍2、声明数组变量类型3、声明变量为环境变量4、声明只读属性5、补充： 1、declare命令介绍 Shell中所有变量的默认类型是字符串类型，如果你需要进行特殊数据类型进行运算，使用declare命令就可以实现声明变量的类型。 declare命令是一个内置命令，命令如…...

编程日记 2023/3/20 23:37:01

墙布的使用窍门和保养清洁方法 - 江南爱窗帘十大品牌

很多业主担心墙布的日常保养，其实很简单，下面就飞大家普及一下关于墙布的使用窍门和清洗保养的小知识~ 1、墙布的保养： 1. 刚开始施工的时候其实就涉及到保养方面的问题，因为墙布贴完以后不能通风，需要自然阴干&#…...

编程日记 2023/3/20 23:37:00

软件项目管理 4.1.软件需求管理过程

软件项目管理 4.1.软件需求管理过程【公众号 “项目管理研究所” 将会第一时间更新文章并分享行业分析报告】归档于软件项目管理初级学习路线第三章生存期模型《初级学习路线合集》前言大家好，这节我们学习软件项目管理---软件需求管理过程，需求管理过程分两个部分。第…...

编程日记 2023/3/20 23:36:58

状态机、混沌状态、机器学习和智能设备

1.机器和状态机机器，英文名字为machine，是指具有某种功能和结构的系统（这是我个人基于系统论和结构-功能主义的定义）。机器的外部属性是具有某种功能，机器的内部属性是具有一定结构，从而帮助一定功能实现。…...

编程日记 2023/3/20 23:36:57

爱奇艺容器实践（内附云原生落地沙龙干货下载）

4月10日下午，爱奇艺技术产品团队举办了“i技术会”线下技术沙龙，本次技术会的主题是“云原生落地探索与实践”，邀请快手、百度和字节跳动的技术专家，与爱奇艺技术产品团队共同分享与探讨云原生落地的实践经验。其中，来…...

编程日记 2023/3/20 23:36:55

css结构伪类

a :nth-child(1) 选择a内部的第一个子元素，不限定子元素的型 a li:nth-child(1 选择a内部的第二个li元素，不能是其他标签 a li:first-child 选择第一个li元素 a li:last-child 选择最后一个li元素 a li:nth-child(n) 选择a标签下的所…...

编程日记 2023/3/20 23:36:51

计算机组成原理笔记，第一章：计算机系统概论

一、计算机的发展与分类世界第一台电子计算机： 用于炮弹弹道轨迹计算的“电子数值积分和计算机”（Electronic Numerical Integrator and Calculator， ENIAC），- - -美国冯•诺依曼思想： （1&a…...

编程日记 2023/3/20 23:36:49

CodeTop每日系列三题------------------2021.11.19

LC143. 重排链表注：这道题涵盖了寻找链表中点，反转链表，合并链表基础中的基础！！ /*** Definition for singly-linked list.* public class ListNode {* int val;* ListNode next;* ListNode() {}* …...

编程日记 2023/3/20 23:36:38

同义词词林图转树

HIT同义词此林的上下位词关系不是树状结构，从图转到树型结构算法： 1.察看word是否有下为词，得到下位词childlist 2.若第一步childlist为空，在entity表中查找该概念对应的实体，否则对于childlist中的每个word若之前…...

编程日记 2023/3/20 23:36:32

java 原子类型

1 CAS -.CompareAndSwap 比较和交换原子类底层实现的基本思想这个操作是cpu 级别的指令 cmpxchg 什么意思就是我们以前一个线程带着自己和自己的从主内存拷贝的数据通过加工产出的期望值就是我想要得到的数据写入主内存会先看看主内存和手里的拷贝的原始数据…...

编程日记 2023/3/20 23:36:29

yarn安装命令

yarn安装 npm i yarn -g 查看版本 Yarn -v 1. 开始一个新工程 yarn init 与 npm init 一样通过交互式会话创建一个 package.json yarn init # yarn npm init # npm # 跳过会话，直接通过默认值生成 package.json yarn init --yes # 简写 -y npm init -y 2…...

编程日记 2023/3/20 23:36:25

HTML+CSS学习

HTMLCSS 目录HTMLCSSHTMLHTML基本格式字体、图像标签超链接锚点链接特殊字符表格标签合并单元格标签列表标签元素textatrea元素CSSCSS语法规范类选择器id选择器通配符选择器字体属性对齐属性装饰文本文本缩进行间距行内样式表外部样式表Emmet语法复合选择器后代选择器子选择器并…...

编程日记 2023/3/20 23:36:06

Java面试宝典！java并发编程详解

01 蚂蚁金服面试题之MySQL 之前的阿里面试题都有做总结，具体面试题内容整理成了文档，本文是针对MySQL系列的，所以下面只展示了自己第一次面试阿里时被吊打问到的一些MySQL难题。 1、请解释关系型数据库概念及主要特点？ 2、请说…...

编程日记 2023/3/20 23:36:01

【Spring Cloud Gateway】学习笔记

【Spring Cloud Gateway】学习笔记一、简介二、核心概念三、代码案例3.1 pom依赖3.2、配置项3.3 启动项四、路由规则4.1、path4.2、Query4.3、Method4.4、Datetime4.5、RemoteAddr4.6、Header五、动态路由5.1、添加依赖5.2、配置项5.3、通过注册中心获取路由5.4、通过服务名称转…...

编程日记 2023/3/20 23:36:01

将Abp移植进.NET MAUI项目（一）：搭建项目

前言去年12月份做了MAUI混合开发框架的调研，想起来文章里给自己挖了个坑，要教大家如何把Abp移植进Maui项目，由于篇幅限制，将分为三个章节。将Abp移植进.NET MAUI项目（一）：搭建项目_林晓lx的博客-CSDN博客将Abp移植进.NET MAUI项目（二）：配置与基类编写_林晓lx的博…...

编程日记 2023/3/20 23:35:57

ajax实现搜索热词下拉列表

<!doctype html><html lang"en"><head><meta charset"UTF-8"><meta name"Generator" content"EditPlus"><meta name"Author" content""><meta name"Keywords"...

编程日记 2023/2/13 7:45:50

测试篇(二)：如何合理的创建bug、bug的级别、bug的生命周期、跟开发产生争执怎么办

目录一、如何合理的创建bug二、bug的等级三、bug的生命周期四、和开发产生争执怎么办一、如何合理的创建bug 创建Bug的目的就是为了能够让其他人可以尝试复现一个合格的bug应该包含以下一个要素： 发现问题的版本例如Web程序对应的浏览器版本，或某个应…...

编程日记 2023/2/13 7:45:32

手机推送信息到本地服务器,服务器信息推送到手机

服务器信息推送到手机内容精选换一换服务器的计费方式为“包年/包月”，如果在计费周期内不想再继续使用，请参考本节指导进行退订。执行退订操作前，请确保待退订的服务器数据已完成备份或者迁移，退订完成后资源将被完全删除&#…...

编程日记 2023/2/13 7:43:10

用户注册调用短信服务接口实现手机号注册

一般现在平台的用户在注册时都是使用手机号注册，所以就需要用到手机介绍短信验证码实现注册，在这里我调用的是榛子云短信平台第三方提供的短信服务发送验证码。短信验证码实现流程 1、构造手机验证码，生成一个6位的随机数字串； 2…...

编程日记 2023/2/13 7:41:27

c语言文件操作（万字解析）

c语言文件操作一.文件的打开与关闭1.文件指针-FILE*2.文件的打开与关闭二.文件的顺序读写1.字符操作函数-fgetc和fputc2.字符串操作函数-fgets和fputs3.格式化函数-fprintf和fscanf4.二进制函数-fread和fwrite5.对比一组函数三.文件的随机读写1.fseek和ftell2.调整指针-rewind四…...

编程日记 2023/3/20 23:01:25

计算机软考英语题翻译,软考专业英语真题、译文及答案.docx

软考专业英语真题、译文及答案09上半年软件设计师英文真题、译文及答案　For nearly ten years, the Unified Modeling Language (UML) has been the industry standard? for visualizing, specifying, constructing, and documenting the (71) of a software-intensive syste…...

编程日记 2023/2/13 7:44:31

软考软件设计师下午真题-面向对象的程序设计与实现-适配器设计模式（2016年上半年试题六））Java代码讲解

软考软件设计师下午真题-面向对象的程序设计与实现-适配器设计模式（2016年上半年试题六））代码讲解说明Java代码注释说明某软件系统中，已设计并实现了用于显示地址信息的类Address（如下图所示）&#xff0c…...

编程日记 2023/2/13 7:46:44

计算机软考程序员试题及答案,2013年计算机软考程序员试题及答案10

3.main(){ int x1，x2，x3，x4;x1x2x3x41;switch(x1){ case 1：switch(x2){ case 0：x3;break;case　1：x4--;｝case 2：x3，x4--;｝printf("%d%d"&#xff0...

编程日记 2023/2/13 7:41:42

2021软考真题答案（系统集成项目管理工程师.上午）

2021年软考上半年系统集成真题及答案解析 1、关于区块链的描述，不正确的是： A. 区块链的共识机制可有效防止记账节点信息被意改 B. 区块链可在不可信的同络进行可信的信息交换 C. 存储在区块链的交易信息是高度加密 D. 区块链是一个分布式共享账本和…...

编程日记 2023/2/13 7:42:51

软考真题答案-2021年11月系统集成项目管理工程师上午题（二）

17、根据应用领域不同，无线通信网络分为：无线个域网、无线局域网____和蜂房移动通信网 A、无线体域网 B、无线穿戴网 C、无线城域网 D、无线MESH网络参考答案：C 解析：无线通信网络根据应用领域可分为;无线个域网（WPAN…...

编程日记 2023/2/13 7:43:14

2021年下半年软件设计师上午真题答案及解析（四）

31、系统可维护性是指维护人员理解、改正、改动和改进软件系统的难易程度，其评价指标不包括( )。 A、可理解性 B、可测试性 C、可修改性 D、一致性参考答案：D 答案解析： 系统的可维护性可以定性的定义为：维护人员理解、改正、改动…...

编程日记 2023/2/13 7:43:08

2022年下半年软考答案+解析估分（网络工程师）

1.下列存储介质中，读写速度最快的是（ ） （1） A.光盘 B.硬盘 C.内存 D. Cache 答案：D 2.使用DMA不可以实现数据（ ） 。 （2） A.从内存到外存的传输 B.从硬盘…...

编程日记 2023/2/13 7:46:36

晶振PPM，PPB单位换算

...

编程日记 2023/2/13 7:40:58

FFmpeg系列-视频解码后保存帧图片为ppm

在正常开发中遇到花屏时怎么处理呢？可以把解码后的数据直接保存成帧图片保存起来，然后直接看图片有没有花屏来排除是否是显示的问题，如果花屏，则代表显示无问题，如果图片中没有花屏，则可以往显示的方向去排…...

编程日记 2023/2/13 7:35:37

PWM和PPM的区别

PWM指的是脉宽调制,狭义说就是舵机信号中正脉冲宽度,就是高电平宽度来表示控制量大小,PPM是脉冲和脉冲之间间隔调制,狭义的说,对于遥控器输出或者接收机输出而言,两个脉冲上升沿之间间隔表示控制量大小.在遥控设备的传统中PWM通常是单通道的控制量,而PPM则是以帧为单位,帧内每个…...

编程日记 2023/2/13 7:37:49

linux bmp图片怎么转换成ppm,[转载]图片解析 ppm图片bmp图片格式

最近用qt编写两个小程序，一个是解析ppm格式的图片，一个是将ppm格式的图片转存为bmp格式图片首先要明确ppm和bmp格式图片的头ppm：头部分由三部分组成，这三部分由回车或换行分割，但PPM的标准中是要求空格。第一行通常是P…...

编程日记 2023/2/13 7:37:53

ppm与LSB含义，换算

n表示ADC位数关于PPM与LSB 一、ppm：百万分之一 ppm是英文part per million的缩写，表示百万分之几，在不同的场合与某些物理量组合，常用于表示器件某个直流参数的精度。下面举例说明。 1.用于描述电压基准（Voltage …...

编程日记 2023/2/13 7:37:29

数字示波器中单位：Kpts, PPM, Sa/s, wfs

Kpts（kilo points）是存储深度的单位,即一次存储多少个数据点,比如5Kpts一次性存储5000个数据点.还有MptsPPM （parts permillion）,是时基精度的单位,即误差百万分之几,比如10ppm在水平时基上有正负百万分之十的误差Sa/s(sample/sec…...

编程日记 2023/2/13 7:37:10

什么是ppm，如何转化到西格玛水平

本文共678字，预计阅读需要2.5分钟我们经常听到，如果一家公司的质量水平达到了六个西格玛水平，那么也就意味着在100万次出错机会中出现的缺陷数不会超过3.4个，也就是3.4ppm。那ppm到底是什么呢？ppm是英文parts per mill…...

编程日记 2023/2/13 7:37:37

ppm/℃是什么单位?什么意思？

在基准电压的数据手册里，我们会找到一个描述基准性能的直流参数，称为温度漂移（也称温度系数）或简称TC（Temperature Coefficient），通常以ppm/℃表示。对于基准电压而言，1ppm/℃表示当…...

编程日记 2023/2/13 7:44:41

生成PPM图像文件

PPM文件是一种图像文件，其结构简单，适合用于菜鸟学习图像处理的原理。 PPM文件主要是由两部分组成，头部分和数据部分。头部信息一般如下： Px ：P是固定字符，x是一个整数，一般x5表示黑白图片&…...

编程日记 2023/2/13 7:37:51

和涤生大数据的故事

1自我介绍大家好，我是泰罗奥特曼，毕业于东北的一所不知名一本大学，学校在一个小城市里面，最热闹的地方是一个四层楼的商城，专业是信息管理与信息系统，由于是调剂的，所以我也不知道这个专业是干…...

编程日记 2023/2/13 7:35:25

ppm值是啥意思

在谈到RTC芯片的精度时，往往会用一个专业词PPM来衡量其精度高精度的RTC精度可达到5 PPM 用PPM不是很直观，那么，此RTC每天的误差是多少秒呢？ 计算如下：（246060s）（510^-6&#xff0…...

编程日记 2023/2/13 7:38:57

单位“ppm”含义

ppm是英文part per million的缩写，表示百万分之几，在不同的场合与某些物理量组合，常用于表示器件某物理量的精度或含量信息。一、溶质浓度用溶质质量占全部溶液质量的百万分比来表示的浓度,也称百万分比浓度。 PPM表示一百万份单位质量的…...

编程日记 2023/2/13 7:38:49

数据中心矩阵历史

基于生成树协议（STP）网络 Convergence 收敛因素：当链路故障或交换机故障时候，需要重新计算树显著地影响流量收敛时间（因为拓扑变化时会导致交换机MAC表被清空）超高的流量收敛时间Unused links 未使用的…...

编程日记 2023/2/13 7:41:00

[读书笔记]云计算时代的网络，读《腾云，云计算和大数据时代网络技术揭秘》...

我很早就有了《腾云，云计算和大数据时代网络技术揭秘》这本书的纸质版，但是一直没有细读；这次借着图灵科技的电子书阅读奖励计划“狠下心”读了起来。正式开始分享笔记之前，先说几句题外话。我们所处的这个时代，很多…...

编程日记 2023/2/13 7:38:47

verlay虚拟化技术_Overlay解决虚拟化难题

传统的数据中心网络基本都为三层架构，主要是以控制南北数据流量为主，由于分布式数据中心及虚拟化和云计算的大规模使用，虚拟机的快速增长以及迁移也成为一个常态性业务，这些都受到了数据中心物理网络能力的约束，主要体…...

编程日记 2023/2/13 7:39:50

如何帮助管理者改进 1:1 面谈和绩效考核

绩效考核和经理一对一都是有效绩效管理过程的关键。但是，它们并不总是以最有效的方式被使用 — 为了获得两者的最佳效果，它们需要被当作不同的、甚至是相关的活动，为员工的绩效和成长目标提供一个方向。如果管理者利用绩效评估会议来简单重…...

编程日记 2023/2/13 7:18:30

verlay虚拟化技术_Overlay 网络技术，最想解决什么问题？

1 云计算虚拟化网络的挑战与革新在云中，虚拟计算负载的高密度增长及灵活性迁移在一定程度上对网络产生了压力，然而当前虚拟机的规模与可迁移性受物理网络能力约束，云中的业务负载不能与物理网络脱离。虚拟机迁移范围受到网络架构限制由于虚拟…...

编程日记 2023/2/13 7:36:37

以太网技术发展杂感

以太网技术一直以来都是被动学习的，现如今，需要它主动一些了。所谓被动，取决于一系列的经验值，比如STP阶段停留时间为15秒，因为按照以太网的规模以及发送速率，30秒内所有的交换机得到的信息会处于一个比较一…...

编程日记 2023/2/13 7:18:33

CCIE理论-第五篇-SDA-2

CCIE理论-第五篇-SDA-2 DNA Center 展示一下web的界面哈其实就类似平时弄的web的防火墙呀,其他设备等弹性子网这一章来讲讲弹性子网 stretched subnets allow an ip subnet to be :stretched:vla the overlay 拉伸子网允许通过覆盖“拉伸”IP子网1基于主机IP的流量…...

编程日记 2023/2/13 7:36:52

CCIE理论-第四篇-SDA-1

CCIE理论-第四篇-SDA-1 SDA-software defied Access SDA-软件定义接入 SDA是被包含在SDN范畴里面的一个架构体系SDA核心-通过一系列的技术合租,组织到一个平面上载体:DNA Center 在华为的载体是AC Agile Contro(不是无线AP哈!) 对比传统传统三层网络 1.要备份,设备多,容…...

编程日记 2023/2/13 7:18:37

HSRP(思科)

如何在公司的住外网网络出现问题时，自动切换到备份网络，此时需要一个新技术 HSRP协议：热备份路由协议 ：备份的是网关 1.HSRP组号：1-255 ，没有大小之分 2.HSRP组里面除了有两台真实路由器网关以外还会有一台…...

编程日记 2023/2/13 7:21:35

软件定义和硬件重构知多少（一）

海量数据和业务增长正以前所未有的趋势冲击着整个各个行业的数据中心，数据中心建设者也正以一种新的思维和模式去审视数据中心IT架构。在这一过程当中出现了两个泾渭分明的阵营：软件定义和硬件重构。以Google、Facebook和国内BA…...

编程日记 2023/2/13 7:17:10

Vue2-Vue开发环境搭建

一、IDE编辑器：Vscode，自行下载安装即可二、三种引入方式， 教程使用方式一引入 Vue官网：https://v2.cn.vuejs.org/v2/guide/installation.html 方式一：直接script引入教程下载开发版本，下载到本地&…...

编程日记 2023/2/13 7:21:26

ITK 读取一个目录中的一个序列，然后改变头信息，将多张dcm图像写成一个dcm文件。

/ Software Guide : BeginCodeSnippet #include "itkImageFileReader.h" #include "itkImageFileWriter.h" #include "itkImage.h" #include "itkMetaDataObject.h" #include "itkGDCMImageIO.h" // Software Guide : EndC...

编程日记 2023/2/13 7:21:19

Tensorflow速查表

TensorFlow 快速查阅指南1. 变量的初始化更进一步 2. tf.contrib.learn学习3. TensorBoard可视化3.1 简单入门3.2 嵌入可视化3.3 图形可视化(Graph) 4. 变量（包含张量的内存缓冲区）5. 张量6. 共享变量7. 线程和队列8. 读取数据9. 监视器 tf.train.Super…...

编程日记 2023/2/13 7:19:32

React Native官方拆包之metro bundle

简介接上一篇《JSBundle拆包之原理篇》快速入门安装安装metro-core依赖主要有两种方式：npm和yarn。npm安装的命令如下： npm install --save-dev metro metro-coreyarn方式的安装命令如下： yarn add --dev metro metro-core运行 me…...

编程日记 2023/2/13 7:17:30

webpack 实现多页面开发相关配置（简单版）

这套多页面开发的目标是不同html文件对应不同的js文件，项目中我们要使用jquery，bootStrap以及stylus等； 那我们就开始吧！ 项目结构 # 我们使用本地引入jquery和bootstrap文件复制代码项目配置创建项目 1.cnpm init 先搭建一个…...

编程日记 2023/2/13 7:18:00

spark源码分析之BypassMergeSortShuffleWriter

概述 spark1.6以后，取消了基于hash的shuffle，只剩下基于sort的shuffle。现在只存在以下三种shuffle writer： BypassMergeSortShuffleWriterUnsafeShuffleWriterSortShuffleWriter 其中，BypassMergeSortShuffleWriter实现带Hash风…...

编程日记 2023/2/13 7:20:37

Ansible@一个高效的配置管理工具--Ansible configure management--翻译（三）

未经书面许可。请勿转载一张图简单概括 Simple Playbooks Ansible is useful as a command-line tool for making small changes. However, its real power lies in its scripting abilities. While setting up machines, you almost always need to do more than one thing a…...

编程日记 2023/2/13 7:17:44

Pytorch04: 用自己的数据实现TextCNN--基于自定义文本数据处理的一个简单文本分类器

写在前面在前面的几篇博客中都是针对图像进行的深度学习，那在本文中将把目光转向文本分类的深度学习，并从处理数据开始，完整实现一个简单的TextCNN模型。目的是文本分类的TextCNN在网络搭建的处理上和VGG-16的过程大同小异，且它…...

编程日记 2023/2/13 7:16:44

表板图建失败_从Google表格构建第3个绘图仪表板应用程序

表板图建失败Plotly Dash应用(Plotly Dash App) So far we have created a free, user-friendly data store and connected to it through the Google Python API.到目前为止，我们已经创建了一个免费的，用户友好的数据存储，并通过Google Pyth…...

编程日记 2023/2/13 7:19:02

如何结合Webpack 4和Babel 7创建一个出色的React应用

I previously wrote an article called “How to conquer Webpack 4 and build a sweet React app.” Soon after I wrote the article, babel swooped in with a major breaking change and many of the packages got deprecated. So I decided to write a new tutorial.我之前…...

编程日记 2023/2/13 7:19:38

合并烧写程序BIN文件的两种方法

在单片机的开发过程中，经常需要将两个单独的BIN文件合并成一个文件，方便烧写和生产。下面结合STM32的IAP Bootloader Code和Application Code的合并，介绍两种合并BIN文件的方法。首先简单介绍一下STM32的IAP。IAP(In-application-programmin…...

编程日记 2023/2/13 7:19:27

学习一个Vue模板项目

最开始学习Vue的时候，不建议直接使用模板，而应该自己从头写起。模板都是人写的，要坚信“人能我能”。只有自己亲自实践，才能促进自己主动思考，才能对模板、框架有深刻的理解。在Github上看到一个Vue的项目模板&#x…...

编程日记 2023/2/13 7:19:30

Keras: 创建多个输入以及混合数据输入的神经网络模型

目录摘要正文Keras: 创建多个输入以及混合数据输入的神经网络模型什么是混合数据?Keras如何接受多个输入?房价数据集获取房价数据集项目结构加载数值和分类数据加载图像数据集定义多层感知器(MLP)和卷积神经网络(CNN)使用Keras的多个输入多输入和混合数据结果总结点击此处下载…...

编程日记 2023/2/13 7:20:43

AS 3.1 多library合并打包成aar的正确方式（fat-aar）

前言主要参考fat-aar来合并打包。但是这个fat-aar很久没维护了，如果直接使用它会有很多问题。由于对gradle脚本也不是太熟，就只能顺着它的意思，将gradle降级成2.2.3的版本。一开始我本地有2.3.3，可以打包，但是打包出…...

编程日记 2023/2/13 7:16:48

关于在iPhone上合并2个应用程序（App）成一个

这次需要做一个把2个iphone游戏合成一个的事情，一开始还没有头绪，所以去论坛上求助高手。回顾下其他平台的做法： Brew平台：可以多个应用程序（app）在一起的，每个app有一个单独的classiD&#x…...

编程日记 2023/2/13 7:17:39

chrome点击书签栏书签_如何将多个书签组织在一起

chrome点击书签栏书签Bookmarklets make a wonderful addition to any browser, but like regular bookmarks they can take up space if you have a large collection. See how easy it is to combine them into a single bookmarklet using the Bookmarklet Combiner website…...

编程日记 2023/2/13 7:19:35

Python编程: 多个PDF文件合并以及网页上自动下载PDF文件

1. 多个PDF文件合并 1.1 需求描述有时候，我们下载了多个PDF文件， 但希望能把它们合并成一个PDF文件。例如：你下载的数个PDF文件资料或者电子发票，你可以使用python程序合并成一个PDF文件，无论是阅读或是打印都更方便…...

编程日记 2023/2/13 7:20:39

洛谷P8942 Digital Fortress

题目大意给定一个区间，构造一个单调不减的序列，使得其前缀异或和与后缀异或和均单调递减，判断这种序列是否存在并输出任意一种解。思路暴力 dfs 当然会 TLE,所以我们要仔细分析： ① 在什么情况下异或和能够单调不减&#x…...

编程日记 2023/2/13 7:20:51

Exception in thread “main“ java.lang.NoClassDefFoundError:org/springframework/core/metrics问题

异常问题原因 spring-core和spring-context的版本不一致所导致解决方法 1、将spring-core和spring-context的版本修改为同一版本 2、直接将<version></version>标签删除...

编程日记 2023/2/13 7:20:05

基于Prometheus自定义指标缩放

再做以下实验时可能会遇到以下问题 1.如果你机器上部署过pp 因为这个东西自带prometheus-adaptor会跟下面的实验冲突，请删除掉 2.如果你的机器可以访问外网，是可以下载原生的image的，如果不能，请按照文档中走 3.如果你kubectl get…...

编程日记 2023/2/13 7:21:24

SpringBoot Caused by: java.lang.ClassNotFoundException: org.springframework.core.metrics.Application

SoringBoot 运行报错 Caused by: java.lang.ClassNotFoundException: org.springframework.core.metrics.ApplicationStartup 我按照网上的方法在pom.xml里面添加 <dependency><groupId>org.springframework</groupId><artifactId>spring-context<…...

编程日记 2023/2/13 7:19:10

Prometheus：Prometheus开发中间件Exporter

Prometheus 为开发这提供了客户端工具，用于为自己的中间件开发Exporter，对接Prometheus 。目前支持的客户端 GoJavaPythonRuby以go为例开发自己的Exporter 2.1依赖包的引入工程结构 [rootnode1 data]# tree exporter/ exporter/ ├── collector │ …...

编程日记 2023/2/13 7:17:13

机器学习--程序报错记录

目录 ModuleNotFoundError: No module named sklearn.cross_validation No module named sklearn.datasets.samples_generator No module named sklearn.cross_validation mean_squared_error is not a valid scoring value. Use sorted(sklearn.metrics.SCORERS.keys()) t…...

编程日记 2023/2/13 7:18:03
