# 论文解读 - 城市自动驾驶车辆运动规划与控制技术综述 (第2部分)

### 文章目录

• 🚗 II. Overview of the decision-making hierarchy used in driverless cars（无人驾驶汽车的决策层综述）
• 🔴 A. Route Planning（路径规划）
• 🟠 B. Behavioral Decision Making（行为决策）
• 🟡 C. Motion Planning（运动规划）
• 🟢 D. Vehicle Control（车辆控制）
• 🚚 III. Modeling for planning and control （规划与控制的建模）
• 🔴 A. The Kinematic Single-Track Model（单轨运动学模型）
• 🟠 B. Inertial Effects（惯性效应）

# 🚗 II. Overview of the decision-making hierarchy used in driverless cars（无人驾驶汽车的决策层综述）

In this section we describe the decision making architecture of a typical self-driving car and comment on the responsibilities of each component. Driverless cars are essentially autonomous decision-making systems that process a stream of observations from on-board sensors such as radars, LIDARs, cameras, GPS/INS units, and odometry. These observations, together with prior knowledge about the road network, rules of the road, vehicle dynamics, and sensor models, are used to automatically select values for controlled variables governing the vehicle’s motion. Intelligent vehicle research aims at automating as much of the driving task as possible. The commonly adopted approach to this problem is to partition and organize perception and decision-making tasks into a hierarchical structure. The prior information and collected observation data are used by the perception system to provide an estimate of the state of the vehicle and its surrounding environment; the estimates are then used by the decision-making system to control the vehicle so that the driving objectives are accomplished.

The decision making system of a typical self-driving car is hierarchically decomposed into four components (cf. Figure II.1): At the highest level a route is planned through the road network. This is followed by a behavioral layer, which decides on a local driving task that progresses the car towards the destination and abides by rules of the road. A motion planning module then selects a continuous path through the environment to accomplish a local navigational task. A control system then reactively corrects errors in the execution of the
planned motion. In the remainder of the section we discuss the responsibilities of each of these components in more detail.

## 🔴 A. Route Planning（路径规划）

At the highest level, a vehicle’s decision-making system must select a route through the road network from its current position to the requested destination. By representing the road network as a directed graph with edge weights corresponding to the cost of traversing a road segment, such a route can be formulated as the problem of finding a minimum-cost path on a road network graph. The graphs representing road networks can however contain millions of edges making classical shortest path algorithms such as Dijkstra [32] or A* [33] impractical. The problem of efficient route planning in transportation networks has attracted significant interest in the transportation science community leading to the invention of a family of algorithms that after a one-time pre-processing step return an optimal route on a continent-scale network in milliseconds [34], [35]. For a comprehensive survey and comparison of practical algorithms that can be used to efficiently plan routes for both human-driven and self-driving vehicles, see [36].

## 🟠 B. Behavioral Decision Making（行为决策）

After a route plan has been found, the autonomous vehicle must be able to navigate the selected route and interact with other traffic participants according to driving conventions and rules of the road. Given a sequence of road segments specifying the selected route, the behavioral layer is responsible for selecting an appropriate driving behavior at any point of time based on the perceived behavior of other traffic participants, road conditions, and signals from infrastructure. For example, when the vehicle is reaching the stop line before an intersection, the behavioral layer will command the vehicle to come to a stop, observe the behavior of other vehicles, bikes, and pedestrians at the intersection, and let the vehicle proceed once it is its turn to go.

Driving manuals dictate qualitative actions for specific driving contexts. Since both driving contexts and the behaviors available in each context can be modeled as finite sets, a natural approach to automating this decision making is to model each behavior as a state in a finite state machine with transitions governed by the perceived driving context such as relative position with respect to the planned route and nearby vehicles. In fact, finite state machines coupled with different heuristics specific to considered driving scenarios were adopted as a mechanism for behavior control by most teams in the DARPA Urban Challenge [9].

Real-world driving, especially in an urban setting, is however characterized by uncertainty over the intentions of other traffic participants. The problem of intention prediction and estimation of future trajectories of other vehicles, bikes and pedestrians has also been studied. Among the proposed solution techniques are machine learning based techniques, e.g., Gaussian mixture models [37], Gaussian process regression [38] and the learning techniques reportedly used in Google’s self-driving system for intention prediction [39], as well as model-based approaches for directly estimating intentions from sensor measurements [40], [41].

This uncertainty in the behavior of other traffic participants is commonly considered in the behavioral layer for decision making using probabilistic planning formalisms, such as Markov Decision Processes (MDPs) and generalizations. For example, [42] formulates the behavioral decision-making problem in MDP framework. Several works [43]–[46] model unobserved different driving scenarios and pedestrian intentions explicitly using a partially-observable Markov decision process (POMDP) framework and propose specific approximate solution strategies.

## 🟡 C. Motion Planning（运动规划）

When the behavioral layer decides on the driving behavior to be performed in the current context, which could be, e.g., cruise-in-lane, change-lane, or turn-right, the selected behavior has to be translated into a path or trajectory that can be tracked by the low-level feedback controller. The resulting path or trajectory must be dynamically feasible for the vehicle, comfortable for the passenger, and avoid collisions with obstacles detected by the on-board sensors. The task of finding such a path or trajectory is a responsibility of the motion planning system, which is discussed in greater detail in Section IV.

## 🟢 D. Vehicle Control（车辆控制）

In order to execute the reference path or trajectory from the motion planning system a feedback controller is used to select appropriate actuator inputs to carry out the planned motion and correct tracking errors. The tracking errors generated during the execution of a planned motion are due in part to the inaccuracies of the vehicle model. Thus, a great deal of emphasis is placed on the robustness and stability of the closed loop system.

Many effective feedback controllers have been proposed for executing the reference motions provided by the motion planning system. A survey of related techniques are discussed in detail in Section V.

# 🚚 III. Modeling for planning and control （规划与控制的建模）

In this section we will survey the most commonly used models of mobility of car-like vehicles. Such models are widely used in control and motion planning algorithms to approximate a vehicle’s behavior in response to control actions in relevant operating conditions. A high-fidelity model may accurately reflect the response of the vehicle, but the added detail may complicate the planning and control problems.This presents a trade-off between the accuracy of the selected model and the difficulty of the decision problems. This section provides an overview of general modeling concepts and a survey of models used for motion planning and control.

Modeling begins with the notion of the vehicle configuration, representing its pose or position in the world. For example, configuration can be expressed as the planar coordinate of a point on the car together with the car’s heading. This is a coordinate system for the onfiguration space of the car. This coordinate system describes planar rigid-body motions (represented by the Special Euclidean group in two dimensions, SE(2)) and is a commonly used configuration space [47]–[49]. Vehicle motion must then be planned and regulated to accomplish driving tasks and while respecting the constraints introduced by the selected model.

## 🔴 A. The Kinematic Single-Track Model（单轨运动学模型）

In the most basic model of practical use, the car consists of two wheels connected by a rigid link and is restricted to move in a plane [48]–[52]. It is assumed that the wheels do not slip at their contact point with the ground, but can rotate freely about their axes of rotation. The front wheel has an added degree of freedom where it is allowed to rotate about an axis normal to the plane of motion. This is to model steering. These two modeling features reflect the experience most passengers have where the car is unable to make lateral displacement without simultaneously moving forward. More formally, the limitation on maneuverability is referred to as a nonholonomic constraint [47], [53]. The nonholonomic constraint is expressed as a differential constraint on the motion of the car. This expression varies depending on the choice of coordinate system. Variations of this model have been referred to as the car-like robot, bicycle model, kinematic model, or single track model.

The following is a derivation of the differential constraint in several popular coordinate systems for the configuration. In reference to Figure III.1, the vectors prp_r and pfp_f denote the location of the rear and front wheels in a stationary or inertial coordinate system with basis vectors (e^x,e^y,e^z)\left(\hat{e}_x, \hat{e}_y, \hat{e}_z\right). The heading θ\theta is an angle describing the direction that the vehicle is facing. This is defined as the angle between vectors e^x\hat{e}_x and pf−prp_f-p_r.

Differential constraints will be derived for the coordinate systems consisting of the angle θ\theta, together with the motion of one of the points prp_r as in [54], and pfp_f as in [55].

The motion of the points prp_r and pfp_f must be collinear with the wheel orientation to satisfy the no-slip assumption. Expressed as an equation, this constraint on the rear wheel is
prp_rpfp_f 的运动必须与车轮的朝向共线，以满足无滑移假设。对于后轮的该约束可以表示为
(p˙r⋅e^y)cos⁡(θ)−(p˙r⋅e^x)sin⁡(θ)=0(III.1)\left(\dot{p}_r \cdot \hat{e}_y\right) \cos (\theta)-\left(\dot{p}_r \cdot \hat{e}_x\right) \sin (\theta)=0 \quad(III.1)

and for the front wheel:

(p˙f⋅e^y)cos⁡(θ+δ)−(p˙f⋅e^x)sin⁡(θ+δ)=0(III.2)\left(\dot{p}_f \cdot \hat{e}_y\right) \cos (\theta+\delta)-\left(\dot{p}_f \cdot \hat{e}_x\right) \sin (\theta+\delta)=0 \quad(III.2)

This expression is usually rewritten in terms of the component-wise motion of each point along the basis vectors. The motion of the rear wheel along the e^x\hat{e}_x-direction is xr:=pr⋅e^xx_r:=p_r \cdot \hat{e}_x. Similarly, for e^y\hat{e}_y-direction, yr:=pr⋅e^yy_r:=p_r \cdot \hat{e}_y. The forward speed is vr:=p˙r⋅(pf−pr)/∥(pf−pr)∥v_r:=\dot{p}_r \cdot\left(p_f-p_r\right) /\left\|\left(p_f-p_r\right)\right\|, which is the magnitude of p˙r\dot{p}_r with the correct sign to indicate forward or reverse driving. In terms of the scalar quantities xrx_r , yry_r , and θ\theta, the differential constraint is

e^y\hat{e}_y 方向的运动写作 yr:=pr⋅e^yy_r:=p_r \cdot \hat{e}_y 。前向速度 vr:=p˙r⋅(pf−pr)/∥(pf−pr)∥v_r:=\dot{p}_r \cdot\left(p_f-p_r\right) /\left\|\left(p_f-p_r\right)\right\|，表示 p˙r\dot{p}_r的大小，同时带有正确的正负号，该正负号用于描述当前的行驶是正向或反向驾驶。利用 xrx_r , yry_rθ\theta这几个标量，微分约束可以写作

x˙r=vrcos⁡(θ)y˙r=vrsin⁡(θ)θ˙=vrltan⁡(δ)(III.3)\begin{aligned} \\ & \dot{x}_r=v_r \cos (\theta) \\ & \dot{y}_r=v_r \sin (\theta) \\ & \dot{\theta}=\frac{v_r}{l} \tan (\delta)\end{aligned} \quad(III.3)

Alternatively, the differential constraint can be written in terms the motion of pfp_f,

x˙f=vfcos⁡(θ+δ)y˙f=vfsin⁡(θ+δ)θ˙=vflsin⁡δ(III.4)\begin{aligned} &\dot{x}_f=v_f \cos (\theta+\delta) \\ &\dot{y}_f=v_f \sin (\theta+\delta) \\ &\dot{\theta}=\frac{v_f}{l} \sin \delta \end{aligned} \quad(III.4)

where the front wheel forward speed vfv_f is now used. The front wheel speed, vrv_r , is related to the rear wheel speed by

The planning and control problems for this model involve selecting the steering angle δ\delta within the mechanical limits of the vehicle δ∈[δmin⁡,δmax⁡]\delta \in\left[\delta_{\min }, \delta_{\max }\right], and forward speed vrv_r within an acceptable range, vr∈[vmin⁡,vmax⁡]v_r \in\left[v_{\min }, v_{\max }\right].

A simplification that is sometimes utilized, e.g. [56], is to select the heading rate ω\omega instead of steering angle δ\delta. These quantities are related by

θ˙=ω,ω∈[vrltan⁡δmin⁡,vrltan⁡δmax⁡](III.7)\dot{\theta}=\omega, \quad \omega \in\left[\frac{v_r}{l} \tan \delta_{\min }, \frac{v_r}{l} \tan \delta_{\max }\right] \quad(III.7)

In this situation, the model is sometimes referred to as the unicycle model since it can be derived by considering the motion of a single wheel.

An important variation of this model is the case when vrv_r is fixed. This is sometimes referred to as the Dubins car, after Lester Dubins who derived the minimum time motion between to points with prescribed tangents [57]. Another notable variation is the Reeds-Shepp car for which minimum length paths are known when vrv_r takes a single forward and reverse speed [58]. These two models have proven to be of some importance to motion planning and will be discussed further in Section IV.

The kinematic models are suitable for planning paths at low speeds (e.g. parking maneuvers and urban driving) where inertial effects are small in comparison to the limitations on mobility imposed by the no-slip assumption. A major drawback of this model is that it permits instantaneous steering angle changes which can be problematic if the motion planning module generates solutions with such instantaneous changes.

Continuity of the steering angle can be imposed by augmenting (III.4), where the steering angle integrates a commanded rate as in [49]. Equation (III.4) becomes

x˙f=vfcos⁡(θ+δ)y˙f=vfsin⁡(θ+δ)θ˙=vflsin⁡δδ˙=vδ(III.8)\begin{aligned} &\dot{x}_f=v_f \cos (\theta+\delta) \\ &\dot{y}_f=v_f \sin (\theta+\delta) \\ &\dot{\theta}=\frac{v_f}{l} \sin \delta \\ & \dot{\delta}=v_\delta \end{aligned}\quad(III.8)

In addition to the limit on the steering angle, the steering rate can now be limited: vδ∈[δ˙min⁡,δ˙max⁡]v_\delta \in\left[\dot{\delta}_{\min }, \dot{\delta}_{\max }\right]. The same problem can arise with the car’s speed vrv_r and can be resolved in the same way. The drawback to this technique is the increased dimension of the model which can complicate motion planning and control problems.

While the kinematic bicycle model and simple variations are very useful for motion planning and control, models considering wheel slip [59], inertia [18], [60]–[62], and chassis dynamics [60] can better utilize the vehicle’s capabilities for executing agile maneuvers. These effects become significant when planning motions with high acceleration and jerk.

## 🟠 B. Inertial Effects（惯性效应）

When the acceleration of the vehicle is sufficiently large, the no-slip assumption between the tire and ground becomes invalid. In this case a more accurate model for the vehicle is as a rigid body satisfying basic momentum principles. That is, the acceleration is proportional to the force generated by the ground on the tires. Taking pcp_c to be the vehicles center of mass, and a coordinate of the configuration (cf. Figure III.2), the motion of the vehicle is governed by

mp¨c=Ff+FrIzzθ¨=(pc−pf)×Ff+(pc−pr)×Fr(III.9)\begin{aligned} &m \ddot{p}_c=F_f+F_r \\ & I_{z z} \ddot{\theta}=\left(p_c-p_f\right) \times F_f+\left(p_c-p_r\right) \times F_r \end{aligned}\quad(III.9)

where FrF_r and FfF_f are the forces applied to the vehicle by the ground through the ground-tire interaction, mm is the vehicles total mass, and IzzI_{zz} is the polar moment of inertia in the e^z\hat{e}_z direction about the center of mass. In the following derivations we tacitly neglect the motion of pcp_c in the e^z\hat{e}_z direction with the assumptions that the road is level, the suspension is rigid and vehicle remains on the road.

The expressions for Fr and Ff vary depending on modeling assumptions [18], [59], [60], [62], but in any case the expression can be tedious to derive. Equations (III.10)-(III.15) therefore provide a detailed derivation as a reference.
FrF_rFfF_f的表达式随建模假设[18][59][60][62]而变化，但在任何情况下，推导该表达式都可能很繁琐。因此，方程(III.10)-(III.15)提供了详细的推导作为参考。

The force between the ground and tires is modeled as being dependent on the rate that the tire slips on the ground. Although the center of mass serves as a coordinate for the configuration, the velocity of each wheel relative to the ground is needed to determine this relative speed. The kinematic relations between these three points are

pr=pc+(−lrcos⁡θ−lrsin⁡θ0)p˙r=p˙c+(00θ˙)×(−lrcos⁡θ−lrsin⁡θ0)pf=pc+(lfcos⁡θlfsin⁡θ0)p˙f=p˙c+(00θ˙)×(lfcos⁡θlfsin⁡θ0)(III.10)\begin{aligned} &p_r=p_c+\left(\begin{array}{c} -l_r \cos \theta \\ -l_r \sin \theta \\ 0 \end{array}\right) \\ & \dot{p}_r=\dot{p}_c+\left(\begin{array}{c} 0 \\ 0 \\ & \dot{\theta} \end{array}\right) \times\left(\begin{array}{c} -l_r \cos \theta \\ -l_r \sin \theta \\ 0 \end{array}\right) \\ &p_f=p_c+\left(\begin{array}{c} l_f \cos \theta \\ l_f \sin \theta \\ 0 \end{array}\right) \\ &\dot{p}_f=\dot{p}_c+\left(\begin{array}{c} 0 \\ 0 \\ \dot{\theta} \end{array}\right) \times\left(\begin{array}{c} l_f \cos \theta \\ l_f \sin \theta \\ 0 \end{array}\right) \end{aligned}\quad(III.10)

These kinematic relations are used to determine the velocities of the point on each tire in contact with the ground, srs_r and sfs_f . The velocity of these points are referred to as the tire slip velocity. In general, srs_r and sfs_f differ from p˙r\dot{p}_r and p˙f\dot{p}_f through the angular velocity of the wheel. The kinematic relation is

sr=p˙r+ωr×Rsf=p˙f+ωf×R(III.11)\begin{aligned} & s_r=\dot{p}_r+\omega_r \times R \\ & s_f=\dot{p}_f+\omega_f \times R \end{aligned}\quad(III.11)

The angular velocities of the wheels are given by

ωr=(Ωrsin⁡θ−Ωrcos⁡θ0),ωf=(Ωfsin⁡(θ+δ)−Ωfcos⁡(θ+δ)0)(III.12)\omega_r=\left(\begin{array}{c} \Omega_r \sin \theta \\ -\Omega_r \cos \theta \\ 0 \end{array}\right), \quad \omega_f=\left(\begin{array}{c} \Omega_f \sin (\theta+\delta) \\ -\Omega_f \cos (\theta+\delta) \\ 0 \end{array}\right) \quad(III.12)

and R=(0,0,−r)TR=(0,0,-r)^T . The wheel radius is the scalar quantity rr, and Ω{r,f}\Omega_{\{r, f\}} are the angular speeds of each wheel relative to the car. This is illustrated for the rear wheel in Figure III.3
R=(0,0,−r)TR=(0,0,-r)^T 。车轮半径用标量 rr 表示，每个轮胎相对于汽车的角速率用 Ω{r,f}\Omega_{\{r, f\}} 表示。图3.3描绘了后轮上的各个变量之间的关系。

Under static conditions, or when the height of the center of mass can be approximated as pc⋅e^z≈0p_c \cdot \hat{e}_z \approx 0, the component of the force normal to the ground, F{r,f}⋅e^zF_{\{r, f\}} \cdot \hat{e}_z can be computed from a static force-torque balance as

Ff⋅e^z=lrmglf+lr,Fr⋅e^z=lfmglf+lr(III.13)F_f \cdot \hat{e}_z=\frac{l_r m g}{l_f+l_r}, \quad F_r \cdot \hat{e}_z=\frac{l_f m g}{l_f+l_r} \quad(III.13)

The normal force is then used to compute the traction force on each tire together with the slip and a friction coefficient model, μ\mu, for the tire behavior. The traction force on the rear tire is given component-wise by

Fr⋅e^x=−(Fr⋅e^z)μ(∥sr∥Ωrr)sr∥sr∥⋅e^xFr⋅e^y=−(Fr⋅e^z)μ(∥sr∥Ωrr)sr∥sr∥⋅e^y(III.14)\begin{aligned} & F_r \cdot \hat{e}_x=-\frac{\left(F_r \cdot \hat{e}_z\right) \mu\left(\frac{\left\|s_r\right\|}{\Omega_r r}\right) s_r}{\left\|s_r\right\|} \cdot \hat{e}_x \\ & F_r \cdot \hat{e}_y=-\frac{\left(F_r \cdot \hat{e}_z\right) \mu\left(\frac{\left\|s_r\right\|}{\Omega_r r}\right) s_r}{\left\|s_r\right\|} \cdot \hat{e}_y \end{aligned} \quad(III.14)

The same expression describes the front tire with the rr-subscript replaced by an ff-subscript. The formula above models the traction force as being anti-parallel to the slip with magnitude proportional to the normal force with a nonlinear dependence on the slip ratio (the magnitude of the slip normalized by Ωrr\Omega_r r for the rear and Ωfr\Omega_f r for the front). Combining (III.10)-(III.15) yields expressions for the net force on each wheel of the car in terms of the control variables, generalized coordinates, and their velocities. Equation (III.14), together with the following model for μ\mu, are a frequently used model for tire interaction with the ground. Equation (III.15) is a simplified version of the well known model due to Pacejka [63].

μ(∥sr∥Ωrr)=Dsin⁡(Carctan⁡(B∥sr∥Ωrr))(III.15)\mu\left(\frac{\left\|s_r\right\|}{\Omega_r r}\right)=D \sin \left(C \arctan \left(B \frac{\left\|s_r\right\|}{\Omega_r r}\right)\right) \quad (III.15)

The rotational symmetry of (III.14) together with the peak in (III.15) lead to a maximum norm force that the tire can exert in any direction. This peak is referred to as the friction circle depicted in Figure III.4

The models discussed in this section appear frequently in the literature on motion planning and control for driverless cars. They are suitable for the motion planning and control tasks discussed in this survey. However, lower level control tasks such as electronic stability control and active suspension systems typically use more sophisticated models for the chassis, steering and, drive-train.
