【JUC系列】ReentrantLock实现本地锁的源码分析

使用场景

public class ReentrantLockTest {private static ReentrantLock lock = new ReentrantLock();public static void main(String[] args) {new Thread(()->{lock.lock();// do somethingSystem.out.println("111");try {Thread.sleep(Integer.MAX_VALUE);} catch (InterruptedException e) {e.printStackTrace();}lock.unlock();}).start();new Thread(()->{lock.lock();// do somethingtry {Thread.sleep(Integer.MAX_VALUE);} catch (InterruptedException e) {e.printStackTrace();}System.out.println("222");lock.unlock();}).start();}
}

在这里插入图片描述

源码分析

默认使用非公平锁。

    public ReentrantLock() {sync = new NonfairSync();}

加锁

ReentrantLock#lock加锁，使用sync进行加锁。

public void lock() {sync.lock();
}

如果当前的状态为0，则设置exclusiveOwnerThread = thread;，表示当前线程占住当前锁对象。

final void lock() {if (compareAndSetState(0, 1))setExclusiveOwnerThread(Thread.currentThread());elseacquire(1);
}

AbstractQueuedSynchronizer#acquire。

public final void acquire(int arg) {if (!tryAcquire(arg) &&acquireQueued(addWaiter(Node.EXCLUSIVE), arg))selfInterrupt();
}

非公平锁的实现，ReentrantLock.NonfairSync#tryAcquire。

        protected final boolean tryAcquire(int acquires) {return nonfairTryAcquire(acquires);}

ReentrantLock.Sync#nonfairTryAcquire。当前状态值为0，直接获取锁，如果锁是当前线程占用，则是可重复锁，state++。

        final boolean nonfairTryAcquire(int acquires) {final Thread current = Thread.currentThread();int c = getState();if (c == 0) {if (compareAndSetState(0, acquires)) {setExclusiveOwnerThread(current);return true;}}else if (current == getExclusiveOwnerThread()) {int nextc = c + acquires;if (nextc < 0) // overflowthrow new Error("Maximum lock count exceeded");setState(nextc);return true;}return false;}

如果没有获取到锁，在队列中等待，执行AbstractQueuedSynchronizer#addWaiter。末尾节点不为空，设置末尾节点为node的前置节点，node为新的末尾结点。

    private Node addWaiter(Node mode) {Node node = new Node(Thread.currentThread(), mode);// Try the fast path of enq; backup to full enq on failureNode pred = tail;if (pred != null) {node.prev = pred;if (compareAndSetTail(pred, node)) {pred.next = node;return node;}}enq(node);return node;}

末尾节点为空，执行AbstractQueuedSynchronizer#enq。进行末尾节点的初始化，再插入node节点。

    private Node enq(final Node node) {for (;;) {Node t = tail;if (t == null) { // Must initializeif (compareAndSetHead(new Node()))tail = head;} else {node.prev = t;if (compareAndSetTail(t, node)) {t.next = node;return t;}}}}

AbstractQueuedSynchronizer#acquireQueued。如果上一个节点是头结点，尝试获取锁。

    final boolean acquireQueued(final Node node, int arg) {boolean failed = true;try {boolean interrupted = false;for (;;) {final Node p = node.predecessor();if (p == head && tryAcquire(arg)) {setHead(node);p.next = null; // help GCfailed = false;return interrupted;}if (shouldParkAfterFailedAcquire(p, node) &&parkAndCheckInterrupt())interrupted = true;}} finally {if (failed)cancelAcquire(node);}}

AbstractQueuedSynchronizer#shouldParkAfterFailedAcquire，前置节点可唤醒，返回true，否则设置前置节点的等待状态为-1。

private static boolean shouldParkAfterFailedAcquire(Node pred, Node node) {int ws = pred.waitStatus;if (ws == Node.SIGNAL)/** This node has already set status asking a release* to signal it, so it can safely park.*/return true;if (ws > 0) {/** Predecessor was cancelled. Skip over predecessors and* indicate retry.*/do {node.prev = pred = pred.prev;} while (pred.waitStatus > 0);pred.next = node;} else {/** waitStatus must be 0 or PROPAGATE.  Indicate that we* need a signal, but don't park yet.  Caller will need to* retry to make sure it cannot acquire before parking.*/compareAndSetWaitStatus(pred, ws, Node.SIGNAL);}return false;
}

AbstractQueuedSynchronizer#parkAndCheckInterrupt，找到唤醒自己的，进入休眠。

private final boolean parkAndCheckInterrupt() {LockSupport.park(this);return Thread.interrupted();
}

解锁

ReentrantLock#unlock。

public void unlock() {sync.release(1);
}

AbstractQueuedSynchronizer#release。如果成功释放锁，且头节点不为空，waitStatus不为0，执行AbstractQueuedSynchronizer#unparkSuccessor。

public final boolean release(int arg) {if (tryRelease(arg)) {Node h = head;if (h != null && h.waitStatus != 0)unparkSuccessor(h);return true;}return false;
}

ReentrantLock.Sync#tryRelease，修改state-1，如果state=0，，则释放exclusiveOwnerThread，返回true，否则返回false。

        protected final boolean tryRelease(int releases) {int c = getState() - releases;if (Thread.currentThread() != getExclusiveOwnerThread())throw new IllegalMonitorStateException();boolean free = false;if (c == 0) {free = true;setExclusiveOwnerThread(null);}setState(c);return free;}

AbstractQueuedSynchronizer#unparkSuccessor。从尾结点找到waitStatus<=0的节点，唤醒

private void unparkSuccessor(Node node) {/** If status is negative (i.e., possibly needing signal) try* to clear in anticipation of signalling.  It is OK if this* fails or if status is changed by waiting thread.*/int ws = node.waitStatus;if (ws < 0)compareAndSetWaitStatus(node, ws, 0);/** Thread to unpark is held in successor, which is normally* just the next node.  But if cancelled or apparently null,* traverse backwards from tail to find the actual* non-cancelled successor.*/Node s = node.next;if (s == null || s.waitStatus > 0) {s = null;for (Node t = tail; t != null && t != node; t = t.prev)if (t.waitStatus <= 0)s = t;}if (s != null)LockSupport.unpark(s.thread);
}

公平锁和非公平锁的不同在于tryAcquire方法。核心在于AbstractQueuedSynchronizer#hasQueuedPredecessors，该方法判断锁同步队列没有多余的节点。

protected final boolean tryAcquire(int acquires) {final Thread current = Thread.currentThread();int c = getState();if (c == 0) {if (!hasQueuedPredecessors() &&compareAndSetState(0, acquires)) {setExclusiveOwnerThread(current);return true;}}else if (current == getExclusiveOwnerThread()) {int nextc = c + acquires;if (nextc < 0)throw new Error("Maximum lock count exceeded");setState(nextc);return true;}return false;
}

总结概括

加锁的逻辑：
- 没有锁，state由0变成1，设置exclusiveOwnerThread = thread;；
- 有锁，且拥有锁的线程和加锁线程是同一个，state++；
- 有锁，但拥有锁的线程和加锁线程不是用一个，队尾添加节点，设置前置节点的waitStatus=-1，进行休眠。
解锁的逻辑。state–，当state=0，释放锁成功，设置exclusiveOwnerThread = null;，唤醒最后一个waitStatus<=0。
