一、创建Electron应用程序

Electron官网

1. 初始化vite项目

npm create vite@latestcd 项目文件
npm install

2. 安装electron

npm install electron -D
npm install vite-plugin-electron -D

electron 安装失败：

# 查看详细安装日志
npm install electron -D  --timing=true --loglevel=verbose# 切换成cnpm安装
## 安装cnpm
npm install -g cnpm --registry=http://registry.npmmirror.com
## cnpm安装
cnpm install electron -D

3. 修改配置文件

vite.config.ts

import { defineConfig } from 'vite'
import vue from '@vitejs/plugin-vue'
import Electron from 'vite-plugin-electron'// https://vitejs.dev/config/
export default defineConfig({plugins: [vue(),Electron({entry: 'electron/index.ts'})],
})

package.json

将 ”type“: "module" 替换为 "main": "dist-electron/index.js"

4. 编写electron文件

import path from "path";
const { app, BrowserWindow } = require('electron');const createWindow = () => {const win = new BrowserWindow({width: 800,height: 600,webPreferences: {contextIsolation: false, // 是否开启隔离上下文nodeIntegration: true, // 渲染进程使用Node API// preload: path.join(__dirname, "../electron-preload/index.js"), // 需要引用js文件}});// 如果打包了，渲染index.htmlif (app.isPackaged) {win.loadFile(path.join(__dirname, "../index.html"));} else {win.loadURL(process.env['VITE_DEV_SERVER_URL'])}
};app.whenReady().then(() => {createWindow(); // 创建窗口app.on('activate', () => {if (BrowserWindow.getAllWindows().length === 0) {createWindow();}});
});// 关闭窗口
app.on('window-all-closed', () => {if (process.platform !== 'darwin') {app.quit();}
});

5. npm run dev 运行

详细请看：Electron + Vite + TS + Vue3打开新窗口实战

二、打包

1. 安装包

# 利用electron-builder来进行打包
npm install electron-builder -D# 调试工具
npm install electron-devtools-installer -D# 辅助工具，快速删除某些文件或文件夹
npm install rimraf -D

electron-devtools-installer github地址

2. 配置打包脚本

修改package.json

修改打包命令： "build": "rimraf dist && vue-tsc && vite build && electron-builder",

添加 build 配置

{......"build": {"appId": "com.electron.desktop","productName": "myElectron","asar": true,"copyright": "Copyright © 2022 myElectron","directories": {"output": "release/${version}"},"files": ["dist"],"mac": {"artifactName": "${productName}_${version}.${ext}","target": ["dmg"]},"win": {"target": [{"target": "nsis","arch": ["x64"]}],"artifactName": "${productName}_${version}.${ext}"},"nsis": {"oneClick": false,"perMachine": false,"allowToChangeInstallationDirectory": true,"deleteAppDataOnUninstall": false},"publish": [{"provider": "generic","url": "http://127.0.0.1:8080"}],"releaseInfo": {"releaseNotes": "版本更新的具体内容"}}
}

3. 渲染进程和主进程的通信

# 安装渲染插件
npm install vite-plugin-electron-renderer -D

配置 vite.config.ts

import { defineConfig } from 'vite'
import vue from '@vitejs/plugin-vue'
import Electron from 'vite-plugin-electron'
import electronRender from 'vite-plugin-electron-renderer'// https://vitejs.dev/config/
export default defineConfig({plugins: [vue(), Electron({entry: "electron/index.ts"}), electronRender()],build: {emptyOutDir: false,}
})

类似发布订阅模式

渲染进程

渲染进程通过 ipcRenderer.on() 和 ipcRenderer.send() 接收/传递信息主进程

<script setup lang="ts">
import { ipcRenderer } from 'electron'// 渲染进程接收主进程传递信息
ipcRenderer.on('load', (_, msg) => {console.log('主进程传递信息 :>> ', msg)
})// 渲染进程传递主进程信息
const send = () => {ipcRenderer.send('msg', 1111)
}
</script><template><div><a href="https://vitejs.dev" target="_blank"><img src="/vite.svg" class="logo" alt="Vite logo" /></a><a href="https://vuejs.org/" target="_blank"><img src="./assets/vue.svg" class="logo vue" alt="Vue logo" /></a></div><button @click="send">发送</button>
</template>

主进程

主进程通过 ipcMain.on() 接收渲染进程传递数据，通过 win.webContent.send() 传递数据至渲染进程

const { app, BrowserWindow, ipcMain } = require('electron');const createWindow = () => {...// 打开调试工具win.webContents.openDevTools()// 主进程接收渲染进程传递信息ipcMain.on('msg', (_, num) => {console.log('渲染进程传递信息 :>> ', num);})setTimeout(() => {// 主进程传递渲染进程win.webContents.send('load', { msg: '初始化完成' })}, 2000)
};
